Loading Port:Zhanjiang
Payment Terms:TT OR LC
Min Order Qty:50 unit
Supply Capability:150000 unit/month
We do research and development ,design, manufacture and sales by ourselves.
We fully support OEM , ODM as well.
Our product lines conform to the latest international safety agency requirements including CE, RoHS, TUV, SAA, EMC, BIS and C-tick standards.
| Model No. | PV-12006P-S | |||
| Output | Output Voltage | 12V±0.5V | ||
| Rated Output Voltage | 12V | |||
| Output current | 0-0.5A | |||
| Power | 6W | |||
| Voltage Precision | ±5% | |||
| Output Ripple | 240mVP-P | |||
| Load Reulation | ±2% | |||
| Start/Rise time | 500ms，20ms/230VAC | |||
| Retention time | 20ms/230VAC | |||
| Input | Input Voltage range | 200-240VAC (170-264VAC) | ||
| Input Frequency range | 50/60Hz | |||
| Effeciency | ≥74% | |||
| PFC | ≥0.55 | |||
| Leak Current | 0.25mA/240VAC | |||
| Protection | Overload Protection | 110-150% | ||
| Protection type : Hiccup mode | ||||
| Working Protection | Working Temperature | -25℃-50℃ | ||
| Storage Temperature | -40℃-80℃ | |||
| IP Rate | IP33 | |||
| Shake Proof | 10-500HZ,2G 10min/1cycle,preiod for 60min,each along X,Y,Z axes | |||
| Temperature Coefficient | ±0.03%℃ (0-50℃) | |||
| EMC | Security Standard | Approved:Design refer to LVD EN61347-2-13:2006,EN61347-1:2008 | ||
| Withstand voltage | I/P-O/P:3.75KVAC | |||
| Insulatuon Resistance | I/P-O/P:>100M Ohms/500VDC/25℃/70% RH | |||
| EMC | EN55015:2006/A2:2009,EN61000-3-2:2006/A2:2009,EN61000-3-3:2008,EN61547:2009 | |||
| Others | Mean Free Error Time | 50KHours (25℃) | ||
| Dimesnsion | 98.5*46*11.2mm(L*W*H) | |||
| Weight | 42g | |||
