Loading Port:Zhanjiang
Payment Terms:TT OR LC
Min Order Qty:50 unit
Supply Capability:150000 unit/month
We do research and development ,design, manufacture and sales by ourselves.
We fully support OEM , ODM as well.
Our product lines conform to the latest international safety agency requirements including CE, RoHS, TUV, SAA, EMC, BIS and C-tick standards.
| Model No. | PV-12150S | ||||||
| Output | Rated Output Voltage | 12V | |||||
| Output current Range | 0-12.5A | ||||||
| Rated Output Power | 150W | ||||||
| Output Voltage Precision | ±3% | ||||||
| Output Ripple | 240mVP-P | ||||||
| Load Reulation | ±2% | ||||||
| Start/Rise Time | 500ms，20ms/230VAC | ||||||
| Retention Time | 20ms/230VAC | ||||||
| Input | Input Voltage Range | 170-264VAC | |||||
| Input Frequency Range | 50-60Hz | ||||||
| Power Efficiency | >87% | ||||||
| Leak Current | 0.25mA/240VAC | ||||||
| Protection | Overload Protection | 110-150% of the output current | |||||
| Protection Type : Hiccup mode | |||||||
| Working Protection | Working Temperature | -25℃-50℃ | |||||
| Storage Temperature | -40℃-80℃ | ||||||
| Ingress Protection Rating | 90%RH non condensing, refer to IP67 | ||||||
| Shockproof Character | 10-500HZ,2G 10min/1cycle,preiod for 60min,each along X,Y,Z axes | ||||||
| Temperature Coefficient | ±0.03%℃ (0-50℃) | ||||||
| Security Features | Security Standard | IP67 approved:Design refer to LVD EN61347-2-13:2006,EN61347-1:2008 | |||||
| Withstand voltage | I/P-O/P:1.5KVAC,I/P-COVER:1.5KVAC,O/P-COVER:500VAC | ||||||
| Insulatuon Resistance | I/P-O/P:>100M Ohms/500VDC/25℃/70% RH | ||||||
| EMC | EN55015:2006/A2:2009,EN61000-3-2:2006/A2:2009,EN61000-3-3:2008,EN61547:2009 | ||||||
| Others | Mean Free Error Time | 50KHours (25℃) | |||||
| Outter Size | 320*42*30mm(L*W*H) | ||||||
| Weight | 680g | ||||||
