Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:5000 g/m²
Supply Capability:10000 g/m²/month
| Packaging Detail: | packing with customer requests |
| Delivery Detail: | after we have received you payment |
Biaxial geogrid:
1)Raw material: Polyproplene;
2)Width: 1.6~2.5m;
3)High Tensile strength
The mateiral of biaxial tension plastic geogrid is similar with the material of unidirectional tension plastic geogrid. Its chemical property isn't active also. It is extruded by macromolecule polymers, and formed by longitudinal and horizontal tension. This kind of material has high tension strength in both longitudinal and horizontal directions. This kind of structure provides a interlock system for the soil.
| Item | TGSG15 | TGSG20 | TGSG30 | TGSG40 | TGSG45 |
| Longitudinal tensile yield strength per long meter | 15 | 20 | 30 | 40 | 45 |
| Horizontal tensile yield strength per long meter | 15 | 20 | 30 | 40 | 45 |
| longitudinal yield elongation rate | 13 | ||||
| Horizontal yield elongation rate | 16 | ||||
| longitudinal resistance to 2%of deformation | 5 | 8 | 11 | 13 | 16 |
| Horizontal resistance to 5%of deformation | 7 | 10 | 13 | 15 | 20 |
| longitudinal resistance to5%of deformation | 8 | 10 | 15 | 16 | 25 |
| Horizontal resistance to 5%of deformation | 10 | 13 | 15 | 20 | 22 |
(1) Road surface reinforcement of road,railway and airport road;
(2)Maintenance,reconstruction and widening of old road surface(asphaltum road or cement concrete road).
(3)Reinforcement of soft soil roadbed,irrigation channels and water dam.
A. Filtration
The filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls.
At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
B. Separations:
The isolation of the railway dregs and the roadbed, roadbed and the soft base, different dam materials.
It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
C. Adding muscle:
The highway, railway of retaining wall, slope protection, etc in which distributes the earth stress,
prevents the side-displacement of the earth body and improves the earth body stability.
D. Protections
It prevents the bank from being washed out, protects the bank and the bottom,
prevents the water and soil from being washed away.
FAQ:
♦ Payment terms: by T/T or L/C |
♦ MOQ:2000 SQM |
♦ If you are interested in our products ,pls advice me the technical index,product weight etc,the more information the better..... |
