Loading Port:Zhanjiang
Payment Terms:TT OR LC
Min Order Qty:50 unit
Supply Capability:150000 unit/month
We do research and development ,design, manufacture and sales by ourselves.
We fully support OEM , ODM as well.
Our product lines conform to the latest international safety agency requirements including CE, RoHS, TUV, SAA, EMC, BIS and C-tick standards.
| Model No. | PV-60-12 | |||
| Output | Rated Output Voltage | 12V | ||
| Output current | 0-5A | |||
| Rated Output Power | 60W | |||
| Voltage Precision | ±3% | |||
| Output Ripple | 240mVP-P | |||
| Load Reulation | ±2% | |||
| Start/Rise time | 500ms，20ms/230VAC | |||
| Retention time | 20ms/230VAC | |||
| Input | Input Voltage range | AC:180-240V | ||
| Input Frequency range | 50-60HZ | |||
| Efficiency | ≥85% | |||
| Leak Current | 0.25mA/240VAC | |||
| Protection | Overload Protection | 110-150% of input current | ||
| Protection type : Hiccup mode | ||||
| Working Protection | Working Temperature | -25℃-50℃ | ||
| Storage Temperature | -40℃-80℃ | |||
| IP Rate | IP20 | |||
| Shake Proof | 10-500HZ,2G 10min/1cycle,preiod for 60min,each along X,Y,Z axes | |||
| Temperature Coefficient | ±0.03%℃ (0-50℃) | |||
| EMC | Security Standard | approved:Design refer to LVD EN61347-2-13:2006,EN61347-1:2008 | ||
| Withstand voltage | I/P-O/P:1.5KVAC,I/P-COVER:1.5KVAC,O/P-COVER:500VAC | |||
| Insulatuon Resistance | I/P-O/P:>100M Ohms/500VDC/25℃/70% RH | |||
| EMC | EN55015:2006/A2:2009,EN61000-3-2:2006/A2:2009,EN61000-3-3:2008,EN61547:2009 | |||
| Others | Mean Free Error Time | 50KHours (25℃) | ||
| Dimesnsion | 110*78*37mm (L*W*H) | |||
| Weight | 210g | |||
