Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:1 set
Supply Capability:20 set/month
| Packaging Detail: | 2* 40 Feet container |
| Delivery Detail: | 2-3 month after down payment |
1 bottom gule spraying section
2 stone coated section
3 first time drying
4 Auto face gule spraying
5.second time drying
Stone Coated Production Line
Stone coated sheet is formed by 0.4mm Al-Zn plating panel and color stones. It is modern,environmental and nice appearance.
We developed this stone coated production line based on long time running and improvement. It is high-performance,stable, energy-efficient and easy operation.
It is including five main parts:
1 Auto bottom gule spraying section
2Auto stone coated section
3 The first time drying section
4 Auto face gule spraying section
5 The second time drying section
Introduction:
1. Auto bottom gule spraying section
Appearance size:4000*1000*2000 Unit:mm
Driving section:3KW Excitation motor or frequency speed regulation (AS per customers’requirements )
Automatic pressure spray tank:1set capability:200kg Range:0.6~1Mpa
Automatic glue machine motor: Servo motor, Power:750w, plc
Automatic spray gun:4 set(spare parts)
Dust collecting fan: 1set power:200w
Damp proof lamp:1pc power:100w
Conveying device:Chain reciprocating
Air compressor:1set power:7.5kw
Dust control of axial flow fan:1set power: 200w
Agitator: 1set power:1.5kw
