Product Name: JP40I Large Output Diesel Mortar Plastering Pump
Technical parameters
Characteristics
1. It has the adjusting function of plastering speed, pressure, output selection.
2. It sets the pressure controlling protection mechanism and achieves the remote control.
3. It’s suitable for narrow environment and space use. And it's easy to move, dismantle and operate.
Standard equipment
Pump equipment Shockproof pressure gage assembly
Variable-speed motor Vibrating screen
Integral control box Wenggong D40
Tool box Operation instruction
Air tube with fast connector ID: ￠13 Delivery hose
GB/T3683 25-1-W.P.10Mpa or GB/T3683 32-1-W.P.9Mpa
Spraying gun with air support (with spraying nozzle)
Model | — | JP40 -I | |
Supply power | — | 380V 50Hz | 220V 50HZ |
Motor power | kw | 3.3/4 | 4 |
Maximum grain size | mm | 5 | |
Output | l/min | 40 | |
Delivery pressure | bar | 30 | |
Horizontal delivery distance | m | 60 | |
Vertical delivery distance | m | 30 | |
Hopper volume | l | 50 | |
Net weight | kg | 200 | |
Dimension (L×W×H) | mm | 1300×640×550 | |
2. Application
JP40-I is smallest plastering machine introduced German technology. It’s applicable to delivery, bonding and plastering for different uses and physicochemical performance of various interior and exterior plastering mortar, masonry mortar, flooring mortar, decorative mortar, thermal insulation mortar, and floor surface mortar.
3. Package
Put into containers.
