Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Forklift Truck Xcpcy 50 Rough Terrain
Model NO.:XCPCY 50
Type:Powered Pallet Truck
Power:Diesel Engine
Load Capacity:1T - 5T
Max. Lifting Height:4000 Mm
Min. Lifting Height:210 Mm
Fork Length:1300 Mm
Fork Width:150 Mm
Model:Cummins 4BTA3.9-C100
Output Power:74 Kw
Running Speed (No Load):22km/H
Lifting Speed(Full Load):300 Mm/S
Certification:CE ISO SGS
Export Markets:Global
Trademark:SWLTD
Packing:Nude
Standard:XCPCY 50
Origin:Mainland, China
HS Code:84272090
Production Capacity:1000 PCS/ Year
CPCY 50 Rough Terrain forklift
Model: CPCY50
Brand Name: SWLTD
Engine: Cummins 4BTA3.9-C100
Structure: Articulated
Payment Terms: L/C, T/T
Introduction
The CPCY50 rough terrain lift truck is an achievement based on Chinese and Australian technologies. Its standard Cummins 4BTA39-C100 engine ensures reduced noise generation and low emission. For flexible and easy handling, the product is equipped with a full hydromechanical transmission, and full hydraulic steering system.
| No. | Item | Unit | Standard model | Optional model | |
| 1 | Rated load | kg | 5000 | 5000 | |
| 2 | Length | No fork | mm | 4420 | 4420 |
| With fork | mm | 5700 | 5700 | ||
| 3 | Width | mm | 2185 | 2185 | |
| 4 | Height | Height of the mast | mm | 3100 | 3100 |
| Height of the cab | mm | 3125 | 3125 | ||
| Full height (under max. lifting height condition) | mm | 4305 | 5805 | ||
| 5 | Wheelbase | mm | 2185 | 2185 | |
| 6 | Front overhang length | mm | 880 | 880 | |
| 7 | Front wheel track | mm | 1575 | 1575 | |
| 8 | Rear wheel track | mm | 1545 | 1545 | |
| 9 | Ground clearance | mm | 285 | 285 | |
| 10 | Max. lifting height | mm | 3000 | 4500 | |
| 11 | Forward/rear tilting angle of mast | ( ° ) | 6/12 | 6/12 | |
| 12 | Dead weight (no-load) | kg | 9500 | 9500 | |
| 14 | Max. lifting speed (Full load) | mm/s | 300 | 300 | |
| 15 | Min. turning radius | mm | 5290 | 5290 | |
| 16 | Max. speed | km/h | 20.0 | 20.0 | |
| 17 | Max. climbing degree (full load) | ( ° ) | 25 | 25 | |
| 18 | Max. drawbar pull (full load) | KN | 30.0 | 30.0 | |
| 19 | Load center distance | mm | 500 | 500 | |
| 20 | Engine model | ---- | Cummins4BTA3.9-C100 | Cummins4BTA3.9-C100 | |
