Forklift Truck 10ton Diesel with Isuzu 6bg1 Diesel Engine

Loading Port:Shanghai

Payment Terms:TT OR LC

Min Order Qty:1 PCS

Supply Capability:2000 PCS/month

Product Description:

Forklift Truck 10ton Diesel  with Isuzu 6bg1 Diesel Engine

Product Details

Basic Info.

Model NO.:CPCD100H



Type:Powered Pallet Truck

Power:Diesel Engine



Load Capacity:5T - 10T

Fuel:Diesel



Load center:500mm

Lift height:3000~5000mm



Condition:New

Brand:JAC



Export Markets:Global

Additional Info.

Trademark:JAC



Packing:JAC Standard Export Packing

Standard:CE/SGS/ISO9001/ISO14001



Origin:Hefei, China

HS Code:8427209000



Production Capacity:20000unit/Year

Product Description

Diesel Forklift: 1-10T,
Tansmission: Mechanic/Auto with TCM design
Engine Brand: JAC, ISUZU, MITSUBISHI, KOBOTA, VM, YANMAR

LPG/Gasoline Forklift: 1-3.5T,
Tansmission: Mechanic/Auto
Engine: Brand: Nissan, BAOFA, GM

Electric Forklift: 1-3.5T, AC Curtis Controller

Warehousing Series: Stacker, Hand Pallet Truck...

JAC J FORKLIFT FEATURES:

1. Stepped-up brand-new structural design
2. Compact forklift body
3. Smaller radius of turn
4. Equiped with high performance engine
5. Advanced machine engineering design
6. Better operation field of vision
7. More convenient maintenance design
8. High performance and low cost
9. With regenerative braking function

CHARACTERISTICS1.1ManufacturerJAC

1.2ModelCPCD100H

1.3Power: battery, diesel, LPG, electric mainsDiesel

1.4Operation: manual, pedestrian, stand, seat, order pickerSeat

1.5Load capacity                                                                  Q (kg)10000
WEIGHT2.1Service weight                                                                     kg13360
WHEELS & TYRES3.1Tyres: P= Pneumatic, V= Cushion , SE= Pneumatic Shaped SolidP
3.4No of wheels front/rear (x = driven)4/2
DIMENSIONS4.1Mast tilt,  α= forward,    β = back                                              Degrees6/12
4.2Height of mast, lowered                                                        h  1  (mm)2845
4.3Free lift                                                                      h 2  (mm)210
4.4Lift height                                                                    h 3  (mm)3000
4.5Height of mast, extended                                                        h 4  (mm)4325
4.6Height of overhead guard  (cabin)                                                h 6  (mm)2560
4.7Seat height                                                                   h 7  (mm)1400
4.8Towing coupling height                                                        h  10  (mm)500
4.9Overall length with standard fork                                                  l 1  (mm)5480
4.1Length to face of forks                                                          l 2  (mm)4260
4.11Overall width (standard/double front tyre)                                       b  1 /b  2  (mm)2245
4.12Fork dimensions                                                             s/e/l (mm)80/175/1220
MOTOR6.1Engine manufacturer / typeXC 6110
6.2Engine power according to ISO 1585                                                  kW83
6.3Rated speed                                                                      rpm2200
6.4Number of cylinders/displacement                                                    cm 380
