Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Electric Forklift Truck (CPD10S, CPD15)
Model NO.:CPD10S, CPD15
Type:Electric Forklift Truck
Power:DC Motor
Load Capacity:1T - 5T
Material:Steel
Export Markets:Global
Trademark:NU-LIFT
Packing:1PC/Pallet
Standard:CE
Origin:Jiangsu, China (Mainland)
HS Code:8427209090
Production Capacity:100PCS/Month
The forklift Model CPD10S and CPD15 is specifically designed and constructed to operate in limited spaces.
Complies with all requirement as regards ease of handling, reliability, safety and high productivity, it combine reduced size and forefront technology.
They are equipped with CURTIS high frequency electronic system with microprocessor and energy recovery braking, standard integrated sideshifter and standard.
They all feature a comfortable diving position where everything is within easy each, from the levels of the distributor to those reversing.
Model | CPD10S | CPD15 | ||
Rated Capacity | (kg) | 1000 | 1500 | |
Load Center | C | (mm) | 400 | 500 |
Max.Lifting Height | H2 | (mm) | 3100 | 3000 |
Free Lifting Height | h | (mm) | 1560 | 125 |
Tilting Angle of Mast | Y1/Y2 | 1/6 | 3/6 | |
Fork Length | L | (mm) | 800 | 900 |
Single Fork Width | B | (mm) | 100 | 100 |
Fork Width | A | (mm) | 200-700 | 200-950 |
Min.Turning Radius | Wa | (mm) | 1225 | 1520 |
Lifting Speed (Unloaded/loaded) | (mm/s) | 153/98 | 500/270 | |
Closed Mast Height | H | (mm) | 2057 | 1975 |
Raised Mast Height | H1 | (mm) | 4175 | 4028 |
Height to safeguard | H3 | (mm) | 1960 | 1980 |
Width (Outside of Front Wheel) | W | (mm) | 820 | 1016 |
Wheel Base | I | (mm) | 991-1057 | 1220 |
Wheel Base of Front Wheel | (mm) | 690 | 886 | |
Ground Clearance | G | (mm) | 101 | 90 |
Traveling Speed (Unloaded/loaded) | (Km/h) | 8.0/6.3 | 12/11 | |
Gradeability (with load) | (%) | 8 | 8 | |
Battery | (Ah/V) | 385/24 | 450/48 | |
Aisle Width for 800*1200 Crossways | AST | (mm) | 2590 | 3180 |
Lifting Motor | (Kw/V) | 2.8/24 | 6/24 | |
Traveling Motor | (Kw/V) | 2.0/24 | 5/24 | |
Overall Size | L1*W*H | (mm) | 1438*820*2057 | 2750 * 1016 *1 980 |
Net Weight | (kg) | 1500 | 2285 |
