Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Model NO.:JE-E20
Rated Loading Capacity:2000kg
Fork Length:1070mm
Fork Width:122mm
Load Center:500mm/ Electric Forklift Truck
Warranty:12 Months
Export Markets:Global
Trademark:JEAKUE
Packing:International Standard Packaging
Standard:CE, ISO, CQC, IAF, CANS
Origin:Anhui
HS Code:8427109000
Production Capacity:2000PCS/Month
Rated Loading Capacity: 2000kg
Fork Length: 1070mm
Fork Width: 122mm
Overall Dimensions: 2375*1150*3990mm
Certification: CE,ISO,CQC,IAF,CANS
After-sales Service Provided: Overseas service center available
Color: Red/Others/4 Wheel Drive Electric Forklift
Manufacturer: Shenchuan Group/Four wheel Counterbalanced Electric Forklift Truck
Wheel Base: 1500mm/4 Wheel Drive Electric Forklift
Fork Overhang: 465mm/Counterbalanced Electric Forklift
Front Tread: 960mm/ Electric Forklift Truck
Rear Tread: 950mm/ 4 Wheel Drive Electric Forklift
Min Turning Radius: 2080mm/Counterbalanced Electric Forklift
Load Center: 500mm/ Electric Forklift Truck
Brand: JEAKUE/4 Wheel Drive Electric Forklift
Ground Clearance: 125mm/Counterbalanced Electric Forklift
| Model | Unit | E20 | E25 | ||||||
| Characteristic | Power Type | Battery | Batery | ||||||
| Rated Capacity | kg | 2000 | 2500 | ||||||
| Load Center | mm | 500 | 500 | ||||||
| Lift Height | mm | 3000 | 3000 | ||||||
| Fork Size LxWxT | mm | 1070*122*40 | 1070*122*40 | ||||||
| Mast Tilt Angle F/R | ° | 6/12 | 6/12 | ||||||
| Turning Radius | mm | 2080 | 2100 | ||||||
| Ground Clearance | mm | 125 | 125 | ||||||
| Overhead Guard Height | mm | 2110 | 2110 | ||||||
| Fork Overhang | mm | 465 | 485 | ||||||
| Performance | Max Driving Speeds(With Load) | km/h | 11 | 11 | |||||
| Max Lifting Speeds(With Load) | mm/s | 220 | 220 | ||||||
| Max Grade Ability With Load | % | 15 | 15 | ||||||
| Dimensions | Overall Length Without Forks | mm | 2375 | 2400 | |||||
| Overall Width | mm | 1150 | 1150 | ||||||
| Overall Height Fork Raised(With Backrest) | mm | 3990 | 3990 | ||||||
| Mast Height | mm | 2010 | 2010 | ||||||
| Chassis | Front Tyres*2 | 700-12-12PR | 700-12-12PR | ||||||
| Rear Tyres*2 | 18*7-8-14PR | 18*9-8-14PR | |||||||
| Wheelbase | mm | 1500 | 1500 | ||||||
| Tread(Front/Rear) | mm | 960/950 | 960/950 | ||||||
| Self Weight | kg | 4130 | 4300 | ||||||
| Drive | Battery | Voltage | V | 48/600 | 48/600 | ||||
| Capacity | Ah | 600 | 600 | ||||||
| Motor | Traction Motor | kw | 7 | 7 | |||||
| Lift Motor | kw | 10 | 10 | ||||||
| Controller | CURTIS | CUTRIS | |||||||
