Loading Port:Tianjin
Payment Terms:TT or LC
Min Order Qty:1 pc
Supply Capability:9999 pc/month
Quick Details
Standard or Nonstandard: | Standard | Structure: | Check | Pressure: | Medium Pressure |
Power: | Manual | Material: | Stainless Steel | Temperature of Media: | Medium Temperature |
Media: | Water | Port Size: | DN50-300mm | Place of Origin: | Tianjin, China (Mainland) |
Model Number: | F7372 | Brand Name: | CMAX | Application: | General |
Item name: | API Forging Check Valves,check valve types,check valve 10 inch | Connection: | Flange | Key words: | check valve |
Usage: | water | Body material: | Carbon Steel, Stainless Steel | Working Temperature: | -40°C~225°C |
Pressure Class: | PN10/16 | Sample: | Packing: | Plywood Case For Check Valve | |
Applicable medium: | water, oil, gas |
| Packaging Details: | PVC package or wooden cases, also according to our customer's requirement.Custom made is accepted.. |
| Delivery Detail: | within 30 days after receiving advancing payment |
Technical Date | Material Specification | ||
Nominal Diameter | DN40-DN1000 | Valve Body | Cast Iron or Ductile Iron |
Nominal Pressure | PN10/PN16 | Valve Disc | Cast Iron or Ductile Iron or Stainless Steel |
Operation Temperature | -40°C~225°C | ||
Flange Driling Standard | EN 1902-2 PN10/16 | Seal Material | EPDM OR NBR |
Suface Treatment | Painting | Valve Spring | Stainless Steel |
