Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:10 m.t.
Supply Capability:100 m.t./month
| Grade: | COM (Common) | Application: | Liners Of Industrial Furnace | Thickness: | 6-60mm |
| Width: | 610/1220mm | Length: | 3.6m/7.2m/14.64m | Chemical Composition: | Al2O3: 46% |
| Ultimate Strength (≥ MPa): | 0.08-0.12Mpa | Fiber Diameter: | 3-5um | Thermal Conductivity: | 0.09-0.16w(m.k) |
| Brand Name: | Place of Origin: | (Mainland) | density: | 64-160kg/m3 | |
| certification: | BV,ISO9001:2000, Rohs, SGS, | working temperature: | 1050C | sample: | aviable |
| Packaging Detail: | . Plastic bag inside and woven bag out side, 620rolls/1x40HQ 2. Plastic bag inside and carton out side, 525ctns/1x40HQ |
| Delivery Detail: | 15-20DAYS AFTER RECEIVING PAYMENT |
Specifications
1. Type:STD, HP, HA, HZ
2. Density:64-160kg/m3
3. Service temp:1050-1350C
4. ISO9001:2000, Rohs report
Ceramic Fiber Blanket is a great energy saving product because of its superior insulating properties and advantages of low heat storage and complete resistance to thermal shock. It is widely used as industrial insulation, high temperature insulation and in a variety of heat processing applications. Ceramic fiber blanket is produced from high strength spun ceramic fibers and is needled to provide exceptional handling or construction strength. KT Refractories stocks large amounts of High quality Ceramic Fiber Blanket in Houston TX: 2300°F or 2600°F Ceramic Fiber Blanket with different width or densities, or thickness. Related Ceramic Fiber Blanket products are also available: ceramic fiber Strips, ceramic fiber modules, ceramic fiber paper, ceramic fiber bulk,ceramic fiber textiles, and ceramic fiber board etc.
New! Ceramic Fiber Strip in stock -- 2300°F 8# 1" thick, 4" or 6" wide Ceramic Fiber Strips in 300" length. Ceramic Fiber Strips are packed in a box of 6 or 4 respectively and they are cut out of Ceramic Fiber Blanket. Ceramic Fiber Strips are soft and commonly used as gasket material.Ceramic Fiber Strip are cut off from Ceramic Fiber Blanket, therefor it has all the insulating advantages and excellert features of ceramic fiber blanket.
Ceramic Fiber Blanket's excellent features and typical applications of Ceramic Fiber Blanket are:
Excellent chemical corrosion-resistant performance without being influenced by oil and water
Excellent construction and tensile strength
Contains no bonding agent, great white color and flat even surface, easy to cut
Very low shrinkage
Ceramic Fiber Blanket for REFINING and PETROCHEMICAL
Reformer and pyrolysis lining
Tube seals, gaskets and expansion joints
High temperature pipe, duct and turbine insulation
Crude oil heater linings
Ceramic Fiber Blanket for STEEL INDUSTRY
Heat treating and annealing furnaces
Furnace door linings and seals
Soaking pit covers and seals
Furnace hot face repairs
Reheating furnace and ladle covers
Ceramic Fiber Blanket for POWER GENERATION
Boiler insulation and boiler doors
Reusable turbine covers
Expansion seals/pipe coverings
Ceramic Fiber Blanket for CERAMIC INDUSTRY
Kiln car insulation and seals
Continuous and batch kilns
Ceramic Fiber Blanket for OTHER INDUSTRY FIELDS
Insulation of commercial dryers and ovens
Veneer over existing refractory
Stress relieving insulation and fire protection
Glass furnace crown insulation
Product information
Item | Ceramic Fiber Blanket |
Type of Blanket | Standard,High Pure, High Aluminum ,Al-Zirconium,Zirconium. |
Classification Temperature | 1260°C,1360°C,1430°C |
Applications | •The industry kiln, heating device, high temperature pipe lining •Power boiler, gas turbine and heat and nuclear power insulation •Chemical industrial high temperature equipment and heating equipment lining •Fireproof and heat insulation for high building •High-grade household appliances thermal insulation device •High temperature filtration etc |
Features | •Low thermal conductivity, low thermal capacity •Excellent thermal stability and good resistance to heat shock •Excellent tensile strength •Good anti-stripping performance •Good Sound-absorbing performance •Non-brittleness material, good flexibility •Excellent machining performance •Resistance to wind and erosion, long service life •Excellent heat insulation, fire prevention, sound absorption performance |
Payment Terms | L/C, D/A, D/P, T/T, |
Delivery Time | Within 15 days after received the deposit. |
Technical data
Type | Common | Standard | High Purity | High Aluminium | Zirconia | |
Classification temperature (°C) | 1100 | 1260 | 1260 | 1360 | 1400 | |
Working Temperature (°C) | < 1000 | 1050 | 1100 | 1260 | 1350 | |
Color | White | Pure white | Pure white | Pure white | Pure white | |
Density (kg/m3) | 96/128/160 | 96/128/160 | 96/128/160 | 128/160 | 128/160 | |
Shrinkage on heating (%) (24 hours, density as 128/m3) | -4 (1000°C) | -3 (1000°C) | -3 (1100°C) | -3 (1250°C) | -3 (1350°C) | |
Thermal conductivity by different temperature (w/m.k) (density as 128kg/m3) | 0.09(400°C) 0.16(800°C) | 0.09(400°C) 0.16(800°C) | 0.09(400°C) 0.16(800°C) 0.20(1000°C) | 0.12(600°C) 0.20(1000°C) | 0.16(800°C) 0.20(1000°C) | |
Tensile strength (MPa) (density as 128kg/m3) | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | |
Chemical composition (%) | AL2O3 | 44 | 46 | 47-49 | 52-55 | 39-40 |
AL2O3+SiO2 | 96 | 97 | 99 | 99 | - | |
AL2O3+SiO2+ZrO2 | - | - | - | - | 99 | |
ZrO2 | - | - | - | - | 15-17 | |
Fe2O3 | <1.2 | <1.0 | 0.2 | 0.2 | 0.2 | |
Na2O+K2O | ≤0.5 | ≤0.5 | 0.2 | 0.2 | 0.2 | |
Size (mm) | 14640/7200/3600×1220/610×6-50; Other sizes can be available. | |||||
Ceramic fiber blanket CHARACTERISTIC Excellent thermal stability Excellent chemistry quality Resistance to burning Low thermal conductivity Low heat storage Good obstructing voice and mechanism strength Low shrinkage Good springiness for fibersConvenient producing and installing
Ceramic fiber mat Application: Joint sealing and filling insulation (kiln car, pipeline, kiln door and so on) Fiber composite (for example: grinding parcel) Internal and external lining for industrial furnace Structure refractory and sponging sounds Materials for hot filtration Raw materials for further producing
