Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Forklift Truck Best Sellings Small and Mini Electric
Model NO.:HTO-FD25
Type:Powered Pallet Truck
Power:AC Motor
Load Capacity:1T - 5T
Load center:500mm
Lift height:3000~5000mm
Export Markets:Global
1. Machine introduction
Electric flrklift truck drives by electric motor, battery as the energy source. Its capacity is 1-4.8 tons, and operation channel width generally is 3.5-5.0m. Due to its advantages of pollution free and low noise, it is widely used in industries have higher environmental requirements, such as medicine and food industries.
2. Machine features
1) compact structure, high operation flexibility;
2) good reliability;
3) high capacity traction battery to ensure sufficient electricity for a day's work;
4) high quality solid tire provides good buffer action;
5) intelligent charger can effectively prolong the service life of battery;
6) applicable to operate in restricted spaces.
Model | HTO-FD20 | HTO-FD25 | HTO-FD30 | |||
Features | Rated Load | kg | 2000 | 2500 | 3000 | |
Load Center | mm | 500 | 500 | 500 | ||
Lifting Height | mm | 3000 | 3000 | 3000 | ||
Free Lifting Height | mm | 135 | 135 | 145 | ||
Fork Size | L×W×H | mm | 1070x122x40 | 1070x122x40 | 1070x125x45 | |
Mast Tilt Angle | Front/Rear | . | 6/12 | 6/12 | 6/12 | |
Minimum Turning Radius | mm | 2240 | 2240 | 2400 | ||
Minimum Stacking Right Angle Channel Width | mm | 4110 | 4110 | 4280 | ||
Minimum Right Angle Channel Width | mm | 2010 | 2010 | 2120 | ||
Minimum Ground Clearance | mm | 110 | 110 | 120 | ||
Front Overhang | mm | 470 | 470 | 475 | ||
Performance | Max.Travelling Speed | Full load | km/h | 19 | 19 | 20 |
Max. Lifting Speed | Full load | mm/s | 490 | 490 | 470 | |
Max. Traction | Full load | KW | 17 | 17 | 18 | |
Max. Climbing Ability | % | 20 | 20 | 20 | ||
Max. Fork Lifting height | With Load Backrest | mm | 4024 | 4024 | 4265 | |
Dimension | Overall Length | Without Fork | mm | 2570 | 2570 | 2695 |
Overall Width | mm | 1160 | 1160 | 1230 | ||
Overhead Guard Height | mm | 2070 | 2070 | 2090 | ||
Mast Landing Height | mm | 1990 | 1990 | 2055 | ||
Weight | Kg | 3350 | 3750 | 4350 |
