Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Forklift Truck 3.0t Gasoline-LPG Duel Fuel with CE
Model NO.:HH30Z-K5-GL
Type:Powered Pallet Truck
Power:Gasoline Engine
Load Capacity:1T - 5T
Load center:500mm
Lift height:3000~5000mm
Export Markets:Global
Trademark:HUAHE
Packing:in Bulk
Standard:2680*1225*2120MM
Origin:China
HS Code:8427209000
Production Capacity:3000PC/Year
1, ZHEJIANG HUAHE FORKLIFT CO.,LTD - recognized brand in China
History: 10 years experience of manufacture IC forklift truck;
Scale: Working area of 30, 000 square meters, more than 300 employees;
Technology: Professional technical engineers and R&D team;
Management: Scientific management and strict quality control system;
Equipments: Advanced automatic production line and test equipment;
Innovation: Continuously diversify products range to satisfy customers;
Production capacity: 400UNITS/month;
Marketing network: America, Europe, Asia, Africa, Middle east, Australia and etc;
2.Speicification:3.0t Gasoline-LPG Duel Fuel Forklift Truck with CE
HUHAE FORKLIFT, 3ton gasoline and LPG duel fuel type
Automatic transmission
With Japanese Nissan K21 gasoline engine
IMPCO transfer system
3M lift height, duplex mast
With sideshifter
Air tires
Others are standard
Specification | 1 | Model | HH30Z-W20-GL | ||
2 | Rated capacity | kg | 3000 | ||
3 | Load center | mm | 500 | ||
4 | Lift height | mm | 3000 | ||
5 | Fork size | L× W× T | mm | 1070× 125× 45 | |
6 | Mast inclination | front/back(α ° /β ° ) | Deg | 6/12 | |
Size | 7 | Overall Dimension | Length(to fork face) | mm | 2680 |
8 | Overall Width | mm | 1225 | ||
9 | Mast lowered height | mm | 2095 | ||
10 | Height When Mast Lifting | mm | 4180 | ||
11 | Safeguard Height | mm | 2120 | ||
12 | Turning Radius min | mm | 2460 | ||
13 | Front Overhang | mm | 490 | ||
14 | Tread | front/back | mm | 1000/970 | |
15 | Ground Clearance min(no load/full load) mast/frame | mm | 152/132158/138 | ||
16 | Wheelbase | mm | 1700 | ||
17 | Fork Spread | min/max | mm | 300/1200 | |
Performance | 18 | Speed | Travel (Laden) | km/h | 20/18.5 |
19 | Lifting (Laden) | mm/s | 480 | ||
20 | Grade ability | Laden | % | 20 | |
21 | Service Weight(include battery) | kg | 4400 | ||
22 | Tire | Front | 28× 9-15-12PR | ||
23 | rear | 6.50-10-10PR | |||
Diesel Engine | 24 | NISSAN K21 WITH LPG DUEL FUEL | Rated Output | Kw/rpm | 32.3/2300 |
25 | Rated Torque | N. m/rpm | 142/1600 | ||
26 | Displacement | cc | 1982 | ||
27 | No. of Cylinder | 4 | |||
28 | Operating Pressure for Attachment | Mpa | 17.5 |
