Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Electric Forklift Truck (1.0-1.5ton)
Model NO.:CPD10-15
Type:Eletric Forklift
Power:AC Motor
Load Capacity:1T - 5T
Export Markets:Global
Trademark:GP
Packing:Seaworthy
Origin:China
Production Capacity:3000PCS/Year
General Manufacturer GP
1. Model: CPD10, CPD15
2. Rated capacity kg: 1000, 1500
3. Load center mm: 500
4. Power type: Battery
5. Tire type Front/Rear: Pneumatic
6. Wheels Front/Rear: 2*2 Dimensions
7. Lift height mm: 3000
8. Free lift height mm: 162.
| General | Manufacturer | GP | |||||
| 1 | Model | CPD10 | CPD15 | ||||
| 2 | Rated capacity | kg | 1000 | 1500 | |||
| 3 | Load center | mm | 500 | ||||
| 4 | Power type | Battery | |||||
| 5 | Tire type | Front/Rear | Pneumatic | ||||
| 6 | Wheels | Front/Rear | 2*2 | ||||
| Dimensions | 7 | Lift height | mm | 3000 | |||
| 8 | Free lift height | mm | 162 | ||||
| 9 | Fork size | L*W*T | mm | 920*100*40 | |||
| 10 | Mast tilt angle | Fwd/Bwd | deg | 6/12 | |||
| 11 | Overall length (without fork) | mm | 2056 | ||||
| 12 | Overall width | mm | 1090 | ||||
| 13 | Mast height fork lowered | mm | 1995 | ||||
| 14 | Overall height fork raised | mm | 4042 | ||||
| 15 | Overall height (overhead guard) | mm | 2162 | ||||
| 16 | Turning radius (outside) | mm | 1820 | ||||
| 17 | Load distance (centerline of front axle to front face of forks) | mm | 429 | ||||
| 18 | Minimum Aisle -90 degree stack(Add load length and clearance) | mm | 3370 | ||||
| 19 | Wheel base | mm | 1250 | ||||
| 20 | Tread | Front | mm | 890 | |||
| 21 | Rear | mm | 920 | ||||
| 22 | Min. Under-clearance | Bottom of mast | mm | 95/110 | |||
| 23 | Bottom of frame | mm | 95/105 | ||||
| Performance | 24 | Speed | Travel Max. | With load | km/h | 11.5 | 11 |
| 25 | Without load | km/h | 13.5 | 13 | |||
| 26 | Lifting | With load | km/h | 300 | 285 | ||
| 27 | Without load | km/h | 400 | 390 | |||
| 28 | Max. Drawbar pull | With/without load | Kn | 6 | 6.5 | ||
| 29 | Max. Gradeability | With/without load | % (fan) | 15 | |||
| Weight | 30 | Service weight | kg | 2900 | 3120 | ||
| Tyre | 31 | Tyre | Size | Front | 6.5-10-10PR | ||
| 32 | Rear | 5.00-8-8PR | |||||
| power control | 33 | Battery | Voltage | V | 48 | ||
| 34 | Capacity | AH | *400/440/480 | ||||
| 35 | Electric motor | drive motor | kw/rpm | 5.3/1700 | |||
| 36 | lift motor | kw | 8.2/1600 | ||||
| 37 | controller | GE separate excitation controller | |||||
| 38 | |||||||
