ZNSJ brown film faced plywood malaysia plywood

Loading Port:China main port

Payment Terms:TT OR LC

Min Order Qty:1000 pc

Supply Capability:100000 pc/month

Product Description:

 ZNSJ brown film faced plywood malaysia plywood

ZNSJ brown film faced plywood malaysia plywood

Dimensions of ZNSJ brown film faced plywood malaysia plywood: 1220*2240*10-20mm),915*1830*(10-20mm)

Product Features of ZNSJ brown film faced plywood malaysia plywood :

1,Adopting the high quality poplar ,whole core and first grade,no holes in the middle of plywood after sawing, which can gurantee the toughness of the template;
2,Using the melamine glue from core to face, high glue concentration, which can gurantee glue adhesiveness ;
3,Adhering them manufacturing principles that each core board is with layer by layer gluing and with high pressure.Layer by layer gluing can fullly bond that impove 10-15% bonding strength. The hot pressure is 120% higher than the theoretical one ,avoiding to reduce pressure to keep the thicknes. The turnover of finished film faced plywood( Concrete formwork panel ZNSJ high quality plywood ) can be up to 10-15time, which ensure product be more durable;
4, two times sanding (secondary molding) before film facing ensure the smoothness of the template without burrs and groove marks.

Product Application of ZNSJ brown film faced plywood malaysia plywood: High- rise construction,building construction, forming concrete,can be widely use for building concrete .



 Items

  Parameters

Plywood size:

 1220*2440mm , 1830*915mm,4*8 ft,3*6ft

Plywood name

Film faced plywood, wooden formwork, wood formwork,

Marine Plywood,Construction Plywood,wooden construction formwork,Concrete formwork panel,shuttering plywood, shuttering formwork,ZNSJ brown film faced plywood malaysia plywood

Glue

Melamine glue/MR WBP

Core

pine,hardwood,eucalyptus,combi etc

F/B

Black film, brown film, anti-slip film

Thickness tolerance:

+/-0.5mm

 Standard quality

natural wood face, one time hot pressing

High quality

double side film faced,twice hot pressing and sanding

thickness:

gross weight    ( kg/pcs)

20ft container

(pcs)

40ft container

(pcs)

Using times

13mm

25.16

690

870

6~15times

14mm

27.12

640

810

6~15times

15mm

29.05

600

750

6~15times

Item

Unit

Standard value

Test result

Moisture

%

6 ~14

 9

Adhesive Force

Mpa

  ≥0.7

 0.76

Bending strength

Longitudinal

Mpa

  ≥24

 36

Cross

  ≥20

 22

Elastic Modulus

Longitudinal

Mpa

  ≥5000

 5980

Cross

  ≥4000

 4850
