Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
Jumbo roll width | 2900mm |
Unfolded size | 190/200±2mm |
Folded size | 95/100±2mm |
Design speed | 170m/min |
Production speed | 140m/min(depend on size) |
Jumbo roll diameter | ≤1500mm(other size to order) |
Unwinding stand | 2~6ply,individual driving(to order) |
Folding system | Vacuum suction folding |
Folding type | V fold interfold |
Cutting system | Upper knife fix, bottom knife rotating |
Transfer structure | Servo control,auto transfer |
Counting | Setting on LCD,auto count and transfer |
Counting model | 100~250sheet |
Transfer speed | ≤7times/min |
Finished products set | Automatic |
Overturn system | Automatic |
Flatting system | Automatic |
Storage | 160PCS |
Max unload speed | 15PCS/min |
Power | 4.4KW |
Cutter model | FC150-2L | FC200-2L |
Speed | 150cuts/min | 200cuts/min |
Feeding line | Double lines | |
Grinding system | Pneumatic grinding,parameter can be set on control panel | |
Grinding feed | Automatic feeding grinding for circular blade | |
Circular blade size | Φ610mm | |
Cutting length | Set on control panel,tolerance≤±1mm | |
Cutting vertical tolerance | Tolerance≤±1mm | |
Cutting length tolerance for two ends | Set on control panel | |
Embossing unit | Steel to steel, steel to rubber |
Edge embossing unit | Steel to steel |
Soft type plastic package | Design conveyor system and soft type plastic packing machine according to production plant |
Carton box package | Design conveyor system and carton box packing machine according to production plant |
