Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
Unfolded finished product Y（mm） | 190/200/210 （other sizes to be specified） |
2 ply of jumbo roll (gsm) | Single ply 13~18gram（other to be specified） |
Maximum jumbo roll diameter（mm） | Φ1200×2850（other size to be specified） |
Core size of jumbo roll | Φ76mm(other size to be specified) |
Machine speed | 110m/min |
Main power（KW） | 5.5-11.5(Depend on the machine model) |
Vacuum power（KW） | 15-30KW(Depend on the machine model) |
Control voltage（V） | 24 |
Cut off | With the upper blades stay still |
Machine framework | The metal plate and welding structure |
Paper detection | Web.break detectors throughout all the unit on the line and auto-stop |
Machine drive | Motor drive,reducer(with chain),timing belt,flat belt,chain,triangle belt |
Jumbo roll loading system | Pneumatic loading system |
Unwind stand | 4-6ply |
Distance of folding rolls | Adjustable |
Paper counter discharge system | Pneumatic paper discharge board |
Paper discharge system | Stepless speed control flat board |
Dimension（mm） | Depend on the machine model |
Weight （kg） | Depend on the machine model |
Option | |
Unwind stand | 4-6ply |
Embossing unit | Steel to steel,steel to rubber |
Edge embossing unit | Steel to steel |
Trimming system | Vacuum suction trimming |
Control system | LCD screen operation panel,MITSUBISHI PLC |
