Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
W136 1.8m3 bucket Joystick control 3Ton Wheel Loader
Packaging & Delivery
| Packaging Details: | 1pc/40HQ |
| Delivery Detail: | 30DAYS |
Standard equipment
• Weichai Engine ZH4100G2-5A 44kw/2400rpm
• Single-turbo hydraulic torque converter and countershaft gear box
• Feicheng drive axle
• Two-way valve for lift arm and bucket
• Lift arm cylinder and bucket cylinder
• Standard lift arm
• Adjustable seat
•Caliper disc brake
• Accumulator 2×12V
•Alternator 28V 750W
• Motor 24V 4.2
Specification | |
Engine | 44KW/2,400rpm |
Rated power | |
Overall dimensions | |
Overall length | 5,860mm |
Overall width | 1,950mm |
Overall height | 2,800mm |
Dump height | 2,680mm |
Dump reach | 890mm |
Tread width | 1,900mm |
Tires type | 16 / 70-20 |
Performance parameters of entire machine | |
Operating weight | 5,600kg |
Bucket capacity | 1.0m3 |
Rated loading capacity | 1,600kg |
Digging Depth(bucket lean forwards 10 degree | 269mm |
Turning radius | 5,230mm |
Gear box | FUDA /SHANTUI |
Number of shifts (forward reverse) | 2/2 |
Fuel tank capacity | 100L |
Hydraulic fuel tank capacity | 100L |
Lifting time | 5.5s |
Total cycling time | 10s |
Travel speed | |
Forward gearⅠ9 km/h | Reverse gearⅠ9km/h |
Forward gearⅡ22 km/h | Reverse gearⅡ22km/h |
Optional Equipment | |
ROPS(roller protective structure) | Loose material bucket, rock bucket, quenched integral cutting edge bucket |
Side dump device, clamping (Pipe or grass) de vice, high dump device | Cool air, warm air, air-condition (cool & hot) |
