Wheel Loader Lw300k 3t Mini
Model NO.:LW300K
Type:Small Loader
Walking Mode:Wheeled
Load and Unload Method:Front Discharge
Certification:ISO9001: 2000
Condition:New
Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:SLCM
Packing:Nude
Standard:CCC
Origin:Shandong, China
HS Code:84295100
Production Capacity:800 Units/ Month
With the two breakthroughs of driving medium and covering part, the machine is ahead of other product of the same kind essentially. The machine is especially adapted to the working conditions of aggregate, earthmoving, coal. The shoveling work efficiency ranks top in the industy.
The performance, efficiency, structural strength, service life, daily maintenance and operation condition are upgraded all round.
All series products adopt superstrong structure, especially for the heavyload work condition.
LW300K features the super large operation weight, long machine body, and strong strength and high efficiency, leading in the industry.
| Item | Parameter | Unit |
|---|---|---|
| Rated load | 3.0 | t |
| Bucket capacity | 1.8 | m 3 |
| Dumping height | 2930 | mm |
| Dumping distance | 1000 | mm |
| Max.drawing force | ≥120 | kN |
| Max. traction | ≥90 | kN |
| Dimension (L × W × H) | 7250×2580×3290 | mm |
| Operating weight | 10.6 | t |
| Boom lifting time | 5.68 | s |
| Total time of three devices | 10.3 | s |
| Wheelbase | 2900 | mm |
| Min. turning radius (bucket outer) | 6067 | mm |
| Rated power | 92 | kW |
| Long boom parameter | ||
| Bucket capacity | 1.5/1.8 | m 3 |
| Rated load | 2.7/2.7 | t |
| Dimension (Length × Width × Height ) | 7540×2580×3290 7640×2580×3290 | mm |
| Dumping height | 3290/3225 | mm |
| Dumping distance | 1092/1172 | mm |
| Operating weight | 10.6/10.8 | t |
| Attachment parameter-grasping grass | ||
| Dumping height | 3043 | mm |
| Dumping distance | 2036 | mm |
| Clamp body width | 2200 | mm |
| Max. opening | 2800 | mm |
| Attachment parameter-clamp( III ) | ||
| Dumping height | 2784 | mm |
| Dumping distance | 1134 | mm |
| Min. circle diameter | 590 | mm |
| Max. opening | 1700 | mm |
| Attachment parameter- side dumping | ||
| Bucket width | 2650 | mm |
| Dimension | 7414×2650×3290 | mm |
| Dumping height (straight/side) dumping | 2813/3623 | mm |
| Dumping distance (straight/side) dumping | 1104/183 | mm |
| Lifting height (straight/side) dumping | 5120/6052 | mm |
| Attachment parameter- Sliding fork | ||
| Fork folding angle | 20 | ° |
| Attachment length | 1575 | mm |
| Attachment width | 1980 | mm |
| Attachment height | 1200 | mm |
| Fork teeth length | 1050 | mm |
