Loading Port:Shanghai
Payment Terms:TT or LC
Min Order Qty:1 unit
Supply Capability:10 unit/month
A leading manufacturer of construction machinery, agricultural equipment and vehicles. Its revenue in 2012 reached RMB 17.76 billion. In 2012, Foton Lovol brand value climbed to RMB 17.736 billion, ranking the 64th among China's top 500 most valuable brands by virtue of its outstanding performance in "Essential growth, structural adjustment and globalization". The Company has been identified as the "national key high tech enterprise" its engineering and technology research institute as the "nation certified enterprise technology center", and moreover, its leading products have been awarded as "Chinese famous brands", "well known trademarks in China" and "most competitive brands on the market"
1. Equipped with YC6B125-T20 engine.
2. Short wheel base, small turning radius and flexible serve for operation in narrow space.
3. Minimum ground clearance is up to 430mm with excellent passing performance
4. Adopted a large vision, all closed damping cab, comfortable operation environment
5. Four-wheeled driving, low-pressure, wide-base, off-highway tires with good performance of passing
| Complete machine parameters of Wheel-loader: FL935E-II | |
| Rated load(kg) | 3000 |
|---|---|
| Operating mass (standard)(kg) | 10020 |
| Bucket capacity(m³) | 1.8 |
| Boom lifting time(S) | 5.8 |
| Sum of three items(S) | 10.5 |
| Max. traction force(kN) | 92 |
| Max. breakout force(kN) | 96 |
| Running system | |
| Forward speed range(km/h) | 0-37 |
| Backward speed range(km/h) | 0-31.5 |
| Gearbox shift | Front : 4 gears rear: 2 gears |
| Max. gradeability(°) | 30 |
| Steering angle(°) | 36 |
| Tire model | 17.5-25-12PR |
| Service brake | caliper disc brake |
| Parking brake | flexible shaft control caliper disc brake |
| Tire center(mm) | 5102 |
| Outside of bucket(mm) | 5945 |
| Hydraulic system | |
| Working system pressure(Mpa) | 16 |
| Working system displacement(ml/r) | 50 |
| Steering system pressure(Mpa) | 14 |
| Steering system displacement(ml/r) | 50 |
| Hydraulic oil volume(L) | 110 |
| Working scope | |
| Outline dimension(mm) | 7066×2424×3230 |
| Wheelbase(mm) | 2630 |
| Track(mm) | 1850 |
| Min. grounding distance (at hinge position)(mm) | 430 |
| Max. unloading height(mm) | 2990 |
| Unloading distance at max. unloading height(mm) | 1100 |
| Engine parameters | |
| Model | Yuchai YC6B125-T20 |
| Type | Six-cylinder, in-line, direct injection, natural inspiration, and water cooling |
| Rated power(Kw/rpm) | 92/2200 |
| Max. torque / speed(N.m/rpm) | 463/1400-1600 |
| Cylinder bore x stroke(mm) | Φ108×125 |
| Displacement(L) | 6.871 |
| Fuel consumption rate at rated working condition(g/Kw.h) | 235 |
| Fuel tank capacityt(L) | 140 |
Pictures of Wheel-loader: FL935E-II
FAQ of Wheel-loader: FL935E-II
(1) What’s Mature technology, strong power, high efficiency?
· More thorough threshing: adoption of tangential flow plus axial flow threshing device, mature material separation technology with strong adaptability, and 90/100hp renowned engine with stronger power
· Widened bridge is conducive to less grain loss
· Capable of threshing and perform a complete and full separation by using tangential + transverse flow
· High-quality engine, powerful engine
· Widened bridge is conducive to less grain loss
Automated, user-friendly, safe and reliable
· Equipped with GPS navigation system (optional) and alarm device for monitoring the revolving speeds of the axial flow cylinder, the re-thresher and the elevator
· It provides a high degree of automation to allow the machine to operate at its best working conditions
· User-friendly instrument equipped with additional sound alarm features for water temperature, oil pressure and oil level
· Using all-brand new disc brake, providing a more reliable braking function.
(2)What’s Easy maintenance, comfortable driving and ride?
· New radiator dust proof cover with high efficiency, providing easy usage and maintenance
· Brand new luxurious cabin in with lower temperature, reduced noise and lower vibration, equipped with built-in air conditioner and luxurious seats, providing a comfortable driving and ride based on ergonomic principles
Multiple purposes machine, high efficiency
· Capable of harvesting rice, rape, soya bean (flexible header), or corn with the special accessories, providing multiple functions to improve the overall economic efficiency
· Straw chopper (optional) available to achieve straw mulching, enhance soil fertility and improve highland productivity
