Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Wheel Loader CE Multi-Function 3.0 Ton (HQ936)
Model NO.:HQ936
Type:Wheel Loader
Usage:Earth Moving
Bucket:Shovel
Transmission:Hydraulic Transmission
Drive Type:Internal Combustion Drive
Bucket Capacity:>1.5m³
Size:Large-Scale
Certification:CE, ISO9001: 2000, CE, SGS,Rops&Fops
Condition:New
Engine:Cummins
Export Markets:Global
Trademark:Haiqin
Packing:1 Unit in One Hq40 Container
Standard:CE, ISO, SGS, ROPS&FOPS
Origin:China
HS Code:84295100
Production Capacity:8000 Units / Year
1, Wheel loader HQ936 advangtates:
1,Fully hydraulic steering system, power shift transmission, easier operation
2,Bucket can be leveled automatically, optimized working device, higher productivity
3,Comfortable operation environment, new design cabin, grammer seat, air conditioning at option
4,Various working devices of attachment are available, such as log clamp, pipe clamp, grass fork, plow, ore bucket, fork etc. To meet different need.
2,Details of HQ936 wheel loader ,we only use the high quality part .
3, Wheel Loader HQ936 ready for loading container
| NO. | Item | Parameters |
| 1 | Specifications | |
| Bucket capacity | 1.7m 3 | |
| Rated load | 3000kg | |
| Transportation dimension(L*W*H) | 7050mm*2430mm*3120mm | |
| Wheelbase | 2760mm | |
| Thread | 1800mm | |
| Max. Breakout,force | 138KN | |
| Max. Dumping height | 3250mm | |
| Dump distance | 1200mm | |
| Total time | 11s | |
| Operating weight | 9600kg | |
| 2 | Engine | |
| Engine Brand and Model | DEUTZ WP6G125E22/ YC6B125-T10 | |
| Pattern | pressurization/inline/water-cooled/4-stroke/direct injection | |
| Rated power/speed | 92KW/2200rpm | |
| Max. Torque | 860N.m | |
| Normal fuel consumption | 162g/kW.h | |
| Total displacement | 6L | |
| 3 | Torque converter and transmission system | |
| Pattern | 3-element single stage | |
| Transmission | Full-power shift,counter shaft type | |
| Number of gear | 4 forward,2 reverse | |
| Max. travel speed | 40KM/H | |
| 4 | Axle | |
| Main reducer Pattern | Arc taper gear model ration of first grade | |
| Pattern of wheelside moderation | ||
| 5 | Tire Size | 17.5-25 |
| 6 | Steering system | |
| Pattern | Articulated and hydraulic steering | |
| Min. Turning radius | 5700mm | |
| Max. turning angle | 37 0 ±1 0 | |
| 7 | Hydraulic system | |
| Displacement | 100ml/r | |
| System working pressure | 27.5Mpa | |
| 8 | Brake system | |
| Service brake | Air assisted oil disc on four wheel | |
| Parking brake | Soft axle control,outside bunch drum type | |
