Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Wheel Loader 2015 Hot Sale Zl-10
Model NO.:ZL-10
Type:Small Loader
Usage:Universal Type
Scraper Type:Pull Scraper
Transmission:Hydraulic Transmission
Walking Mode:Wheeled
Load and Unload Method:Front Discharge
Engine Power:<74kw
Certification:CE, ISO9001: 2000
Condition:New
Export Markets:Global
Trademark:Impetus
Packing:in Nude
Standard:CE
Origin:Qingdao, China
Production Capacity:1000 Units
2015 Hot Sale ZL-10, 1000kg mini wheel loader
1). The chassis uses swing joint structure, whose turning radius is minor, which can turn flexibly angle is suitable to work in poky areas.
2). It adopts directly in ejections diesel engine 385 for power, which is start and consumes less oil, whose power is 22KW.
| Main Specification for ZL-10 | |
| Item | ZL10 |
| Rated load(kg) | 1000 |
| Bucket capacity(m3) | 0.5 |
| Wheel distance(mm) | 1320 |
| Axle-base(mm) | 2150 |
| Loader clearance radius(mm) | 4700 |
| Mini base to the ground(mm) | 230 |
| Dump clearance(mm) | 2680 |
| Distance acc.to the height(mm) | 800 |
| Time of raise(s) | 4 |
| Hydraulic cycle time(s) | 9 |
| Turns to pick the strength mose greatly(kn) | 32 |
| Drive ways | four wheel drive |
| Operating weight(kg) | 2500 |
| Overall dimensions(mm) | 4950*1730*2530 |
| Engine model | Changchai 385 |
| Engine rated power(kw) | 20 |
| Engine rated output(rpm) | 2200 |
