WASTECOM CPS Screw Compactors

Product Description:

WASTECOM CPS Screw Compactors consist of a conveyor trough manufactured from stainless steel, a shaftless extra heavy-duty spiral manufactured from carbon steel, a compacting and de-watering discharge module, a return duct for pressed out water, and a drive unit suitable for the application.

Function

Three functions in one unit: conveying, de-watering and compacting.
Designed for intermittent operation, WASTECOM CPS Screw Compactors can be employed in various de-watering applications and in combination with different type solids-liquid separators or conveyors. Usually applied for compacting various solids from different processes (municipal/industrial waste water treatment, food processing, slaughterhouses, rock wool industries, plastics recycling processes, etc.).

Features

• Fabricated structure completely manufactured from 304L / 316L SS

• Highly wear-resistant extra heavy-duty mild steel or 304/316 SS spiral

• Trough liner manufactured from HDPE high-density, low-friction polymer

• No outlet and intermediate bearing assemblies

• No mechanical components in contact with material handled

Benefits

• Two functions: conveying and compacting

• Up to 40% reduction of screenings volume

• Particularly maintenance-friendly modular design

• No machine locking even with fibrous materials

• Fully enclosed, pollution-free, odour-free

• Low noise level

• Low energy consumption

Options

• Compacting screen basket mesh

• Trough liner

• Drive guard

• Alternative voltage/frequency

• Alternative degree of motor protection

• Control panel

• Compaction washing system

Accessories

• Outlet verticaliser

• Endless tube

• Bag fastening system

• Rectangular inlet

• Adjustable support stands

• Support bracket

• Plug retention SINT diaphragm with different resistance levels
