WAMFLO Flanged Round Dust Collectors

Product Description:

The WAMFLO Dust Collector range is the result of WAM’s decades of experience in dust filtration technology. Since it went into production shortly after the turn of the millennium, tens of thousands of units have left the Group’s manufacturing plants all over the world. In diverse configurations WAMFLO has proved to be suitable for a variety of applications in virtually all industries.

WAMFLO Dust Collectors are equipped with a cylindrically shaped stainless steel body and flanged bottom ring which contains vertically mounted filter elements of various types including the high efficiency POLYPLEAT. An air jet filter element cleaning system is integrated in the hinged top cover. WAMFLO Dust Collectors are available with or without suction fan. As an option for applications with top-mounted suction fan or in case of limited headroom, WAMFLO can be equipped with a large front door which facilitates access to the filter elements in case of inspection or maintenance. In the food-grade version WAMFLO comes in a zero dust residue design. WAMFLO is supplied with an integrated modular electronic panel able to manage cleaning cycles according to the specific requirements of the work process. It is suitable for operation in explosive environments.

Function

WAMFLO Dust Collectors are used for both venting and suction applications. The unique design of the integrated compressed air jet cleaning system guarantees high efficiency, thus minimising maintenance and reducing total plant cost ownership. Moreover, the WAMFLO design with its flanged bottom meets the highest demands regarding health and safety.


Features

• 304 stainless steel cylindrically shaped body with bottom flange

• Filter surface: 1 ~ 48 m² (11 ~ 517 sq ft)

• Air volume: 60 ~ 4,500 m³/h (35 ~ 2,650 cfm)

• High filtration efficiency thanks to WAM filtering elements

• Easy maintenance and filtering element replacement

• Multifunctional, intelligent electronic control panel

• Filter elements: round bags, elliptical bags, cartridges, POLYPLEAT

• Comfortable maintenance height

• Compressed air jet cleaning system integrated in top cover

• High cleaning efficiency due to "Full Immersion" solenoid valves incorporated in corrosion-resistant air  tank for low-on-maintenance operation

• Safe weather protection cover with lockable quick release

• Tool-free filtering element removal

• Increased durability

• Reduced maintenance costs

• Hygienic operation

• Increased work safety

• Low operating costs (TCO)

• Food grade made with all material FDA and EU1935/2004 certified

• Exceptional price-quality ratio

Benefits

• Industrial design

• Wide range of high quality filtering elements

• Advanced dust filtration technology

• Low emission level due to B.I.A.-certified filter media

Options

• 316L stainless steel cylindrically shaped body with bottom flange

• Suction fan

• Connection for centralised dust suction

• Electronic differential pressure meter (MDPE)

• WAMFLO Front: complete with large access door for filter element removal from dirty side

• Dust collecting hopper with bucket, butterfly valve or rotary valve, and flow aids

• Winter protection for solenoid valves
