Vinyl (PVC) Flooring - Wood Plank

Loading Port:China Port

Payment Terms:TT or L/C

Min Order Qty:1 X 20'GP m²

Supply Capability:50 X 20'GP Per Month m²/month

Product Description:

Description of Vinyl (PVC) Flooring

Vinyl (PVC) Flooring is an affordable option that offers style, durability, and long-lasting performance.  When installed correctly over proper subflooring, it is extremely resistant to dents, scratches, and stains.  Vinyl is easy to install yourself, and is also simple to clean and maintain.  One of the main attractions of vinyl is that it is very durable which makes it great for high-traffic rooms.  Another quality of vinyl flooring is that it can be made to resemble the look of other flooring types, like hardwood, stone and ceramic.  You can create any style you want with vinyl.  Choose black and white checkerboard for a retro feel or choose a natural look for an up-scale, classic approach.



Features of Vinyl (PVC) Flooring

· Incredibly realistic photo replication of natural materials

· Brands that offer 100% vinyl material

· Inherent safety features

· Ease of maintenance

· Excellent selection of sizes, shapes

· Naturally water resistant

· Scratch, stain, dent and scuff resistant

· Cost effective

· Exceptional durability

· More resilient than other hard surface floors

· Amazing aesthetics

features of Vinyl (PVC) Flooring



Structure of Vinyl (PVC) Flooring

Structure of Vinyl (PVC) Flooring

Specifications of Vinyl (PVC) Flooring

Size: 3" x 36" (76.2 x 914.4mm), 4" x 36" (101.6 x 914.4mm), 6" x 36" (152.4 x 914.4mm), 9" x 36" (228.6 x 914.4mm), 9" x 48" (228.6 x 1219.2mm)

Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm
                    4.0mm, 5.0mm, 6.0mm available for Click System

Wear Layer: 0.1mm, 0.2mm, 0.3mm, 0.5mm, 0.7mm



Technical Specifiations of Vinyl (PVC) Flooring

Characteristic

Standard

Test Result

Resistance to chemicals

DIN  EN423:93

Class O

Bearing a castor chair

DIN  EN425:94

No obvious damage

Dimension

DIN  EN427:94

±0.1mm(side length<200mm)

±0.25mm(side length>200mm)

Squareness and straightness

DIN  EN427:94

≤0.15mm(side length<400mm)

≤0.2mm(side length>400mm)

Thickness-overall

DIN  EN428:93

±0.10mm

Thickness-wearlayer

DIN  EN429:93

±0.01mm

Mass per unit area

DIN  EN430:94

pass

Peeling strength of layers

DIN  EN431:94

>1.8kn/m

Residual indentation after static load

DIN  EN433:94

≤0.05mm

Dimensional stability and curling after exposure to heat

DIN  EN434:94

Shrinkage rate≤0.15%

Curling≤1.0mm

Flexibility

DIN  EN435:94

pass

Abrasion Resistance

DIN  EN660-1:99

<0.068mm

Color fastness to light

DIN  EN20105-B02

≥Crade 6

Flammability

DIN  EN71-2

pass

Toxic element test

DIN  EN71-3

pass

Specific gravity

ASTM  D792:91

pass

Fungus Test

ASTM  G21:96

Grade 1



hot pressing of Vinyl (PVC) Flooring

heating & cooling stabilization  of Vinyl (PVC) Flooring

click milling of Vinyl (PVC) Flooring

quality control of Vinyl (PVC) Flooring

pallet packing of Vinyl (PVC) Flooring

container loading of Vinyl (PVC) Flooring
