Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Tractor Truck Ud 6X4 Euro IV 370-420HP
Product Details
Model NO.:UD tractor
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 4
Drive Wheel:6×4
Seats:≤5
Horsepower:351-450hp
Engine Capacity:＞8L
Tire Type:Solid Tire
Tire Certification:ISO
Tire Design:Radial
Condition:New
Brand:Nissan Ud
Total Weight:25000kg
Rated Load:16225kg
Curb Weight:8775kg
Fuel Type:Diesel
Axles Number:3
Wheel Base:3200+1370/3400+1370
Axles Load:7000/18000
Steel Spring Number:3/9
Tire Number:10
Export Markets:Global
Trademark:UD
Origin:China
Production Capacity:50000PCS/Year
| Driving Type | 6x4 | ||
| Wheel Base (mm) | 3200+1370 | 3400+1370 | |
| Overall Length (mm) | 6835 | 7035 | |
| Overall Width (mm) | 2499 | 2499 | |
| Overall Height (mm) | 3730 | 3730 | |
| Wheelspan | Front (mm) | 2020 | |
| Rear (mm) | 1836 | ||
| Engine | Model | GH1A | |
| Displacement (L) | 10.8 | ||
| Max Output (kw) | 280 | ||
| Max Output (HP) | 370 | ||
| Announcement Model | DND4250WA32 | Announcement Batch | 256 |
| Rated Load(kg) | 16225 | Total Weight(kg) | 25000 |
| Curb Weight(kg) | 8775 | Fuel Type | Diesel |
| Emmission Standard | Euro IV | Axles Number | 3 |
| Front/Rear Suspension | 1460/805 | Axle Load | 7000/18000 |
| Steel Spring Number | 3/9 | Tyre Number | 10 |
| Tyre Size | 315/80R22.5 16PR, 295/80R22.5 16PR | Approach/Departure Angle | 14/43 |
| Front Wheelspan | 2020 | Rear Wheelspan | 1836/1836 |
| Top Speed(km/h) | 120 | Max Weight of Semi Trailer(kg) | 40000 |
