Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:5000 kg
Supply Capability:500000 kg/month
Small pitch availiable
Customed as required
Acme thread rod
1-12 starts as required
Product Description
| Product Detail: | |
| Product name | Acme thread rod |
| External Diameter | ¢6mm to ¢40mm, tolerance can be controlled in 0.01mm |
| Pitch | 0.5mm to 4.0mm, tolerance can be controlled in 0.005mm |
| Lead | 0.5mm to 20mm |
| Start of thread | 1-12P |
| Length | 20mm to 2500mm, tolerance can be controlled in 0.03mm |
| Screw Direction | Right hand, Left hand, RH & LH. |
| End machining | Full thread or customized |
| Processing for two ends machining | To makesure the concentricity of part, the process finished in one time: CNC cutting, truning, milling flat, milling gear, cutting slot, drilling hole, Tapping and others as required. |
| Material | Stainless steel, steel, iron, aluminum/alloy, copper/alloy, brass, bronze, Cr40, plastic and others as required. |
| Surface treatment | High Frequency Hardening, Teflon, Heat treatment, surface hardening,Accurate grinding and others as required. |
| Client base | Auto industry, Mechanical industry, Medical equipment, Solar energy field, furniture, Door & Window, security and protection etc. |
| Lead time | 7-15 days common according to quantity |
| QC System | 100% inspection before shipment |
Packaging & Shipping
Packing: | In bulk/box+carton+pallet |
packing as customer needed | |
Delivery time: | 30~45 Days after order confirmed |
Our Services
Our service: | 1.Timely reply your inquiry and doubt |
2.Timely production and delivery | |
3.With 100% inspection prior to shipment | |
4.Highly competitive prices with the industry | |
5.Help solve problem after sales |
FAQ
1. Q: How about the quality of your product?
A: 100% inspection during production.
Our products are certified to ISO9001,
TS16949 international quality standards.
2. Q: What's the delivery time?
A: For custom order, within 20 tons,
production time is 30--35days after confirmed every details.
3. Q: What's your packing?
A: Our Normal packing is bulking in Cartons, and then in pallet.
We also can pack products according to your requirement.
4. Q: What about the warranty?
A: We are very confident in our products,
and we pack them very well to make sure the goods in well protection.
5.Q: Could you send me your catalogue and price list?
A: As we have more than hundreds of products,
it is really too hard to send all of catalogue and price list for you.
Please inform us the style you interested,
we can offer the pricelist for your reference.
