Loading Port:China main port
Payment Terms:TT or LC
Min Order Qty:2 unit
Supply Capability:30 unit/month
| |
Overall size (mm) | 11980(L)* 2500(W)*3950(H) |
Tank body dimension(mm) | 9600*2500 |
Wheel base (mm) | 1800+4600+1350 |
Min. ground clearence(mm) | 260 |
Min. turning diameter(m) | 24 |
85 | |
Chassis | |
Manufacturer | Sino truck |
Model | ZZ1317M4669V |
Steering system | Power steering |
Transmission | Manual, 10 speeds |
Brake system | Dual circuit air-pressure braking system |
Tyre | Radial tyre, amount:12+1, type: 12.00R20 |
Air-condition | A/C in cab |
Engine | |
Model | WD615.93 |
Max. Power (hp) | 290 |
Engine type | L6, four strokes, water-cooled, supercharged inter-cooling |
Fuel type | Diesel oil |
Tank body parameter | |
40 | |
Rated pressure (Mpa) | 0.2 |
Discharge speed (t/min) | More than or equal to 1.2 |
Discharge residual (%) | Less than 0.3 |
Top structure | |
Tool box | One |
Compressor | Suzhou9.0 |
It has a good reputation all over the world and we have competitive price and good after-sales service.
Model
