Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:30 unit/month
· Customer can tell Masan the detailed specifications and Masan can make the suitable products for customers.
· Manufacturing Year: 2014
· Jib Length: 60m
· Free Height Under Hook: 50.7m
· Max. Load: 10T
· Tip load: 2.2T
· Mast Section Dimension(m): 2x2x3(L66)
· Hoisting Speed(m/min) & power: 0~85 45Kw frequency
· Slewing Speed (r/min) & power: 0~0.8 2x5.5Kw frequency
· Trolleying Speed (m/min) & power: 0~58 7.5kw frequency
· Cable specification: 3x25+2x16
· Power Supply: 400V(+6% -10%)50HZ
