Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Tank Truck 8X4 30m3 Beiben for Fuel Transportation
Model NO.:ND1319D47J
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 3
Tank Volume:15001-30000L
Drive Wheel:8×4
Seats:6-9
Horsepower:251-350hp
Engine Capacity:＞8L
Storage:Oil
Tire Type:Solid Tire
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Radial
Condition:New
Engine:Weichai Wp10.290e32
Rated Power:290HP Euro3
Drive Type:8X4/LHD
Tank Capacity:30cbm
Dimensions:12000X2500X3650 Mm
Technology:Mercedes Benz
Export Markets:Global
Trademark:BEIBEN/NORTH BENZ
Packing:Nude Packing
Standard:ISO9001
Origin:China Mainland
HS Code:870423009
Production Capacity:10, 000units/Year
Engine: Weichai WP10.290E32
Rated Power: 290HP(EuroIII)
Drive Type: 8x4/LHD
Cab: Long cab with one sleeper ,air conditioner
Tank Capacity: 30CBM
Dimensions: 12000x2500x3650 mm
Technology: Mercedes Benz
| Chassis | |
| Model | ND1319D47J |
| Traction type | 8X4 |
| Driving type | LHD |
| Driver's cab | Long cabin, one sleeper, A/C |
| Wheel base | 1500+4750+1450 mm |
| Overall Dimensions | 12000x2500x3650 mm |
| Engine | Maker: WEICHAI |
| Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling | |
| Engine model: WP10.290E32 | |
| Clutch | 430mm, hydraulically operating with air assistance |
| Transmission | FAST 9JS150A |
| Steering | TAS85 |
| Front Axle | Benz front axle 6.5 ton |
| Rear Axle | Benz strengthened type 13T, double reduction drive axle Ratio: 5.263 |
| Spring | 12/12/13 |
| Types | 12.00R20 |
| No. of tyre | 12+1(spare) |
| Fuel tank | 400L Aluminum |
| PTO | QH50 |
| Electrics | Operating voltage: 24V, negative grounded |
| Kerb weight | 12920 kg |
| Body | |
| Tank Volume | 8000 Gallons |
| Oil-in&oil out | Europe Standard |
| Thickness | Tank 6mm |
| Steel Material | Q235, with 5 pcs reinforcing plate inside |
| Other | Safety Sea Valve for emergency braking, oil gas recycling device |
