Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
Model: | FM150 | |
Max.working height | 15M | |
Max.platform height | 13M | |
Loading capacity | 200kgs | |
Lateral Outreach | 6.2M | |
Platform rotation | — | |
Jib rotation | 100° | |
Turntable rotation | 350° non- continuous | |
Size of platform | 0.95×0.65×1.1M | |
Overall stowed length | 5.16M | |
Overall stowed width | 0.9M | |
Overall stowed height | 2.10M | |
Power capacity |
| |
Standard power source | diesel engine | |
220V AC power | ||
Driving speed | 0-1.5KM | |
Max climbing ability | 30° | |
Total weight | 1900kgs | |
