Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 set
Supply Capability:1000 set/month
1. The specification of generator set:
1.generator set powered by Cummins diesel engines respectively in China.
2.generator set equipped with famous alternators.
3.generator set strict tests before sale.
4.generator set features at low oil consumption, stable performance, easy maintenance, low operation cost, low emission.
2. Techncial Data Sheet
Genset’s Data | ||
Genset Model | TP22 | |
Prime Power | 20KVA/16KW | |
Standby Power | 22KVA/18kW | |
Rated Voltage | 440/254V (Adjustble) | |
Frequency | 50Hz | |
Radiator | 50°C suitable for tropical weather | |
Charge Alternator | 12V | |
Dimension(L*W*H) (mm) | 1300*600*1150 (Open genset ) | |
Dimension(L*W*H) (mm) | 2000*950*1050 (Silent genset) | |
Net Weight (kg) | 550KG/760KG with canopy | |
Base Fuel Tank Capacity | Enough for Genset 8-10 Hours Continuous Running | |
Diesel Engine Data | ||
Brand | Parkins | |
Model | 404D-22G | |
Governor Type | Mechanical | |
Rotating Speed | 1500 rpm | |
Engine Cooling Method | Water-cooled | |
Cylinder Nos. | 4 | |
Fuel consumption | 4L/h @75% full load | |
Alternator Data | ||
Brand | Original Stamford/Tang Power Stamford/Leroy-somer | |
Model | PI144D | |
Power Factor(COS Phi) | 0.8 | |
Excite Type | SHUNT | |
Connecting Type | 1 Phase & 4 Wires | |
Insulation Degree | H | |
Enclosure Degree | IP23 | |
AVR voltage regulation rate | ≤±0.5% | |
3. Generator set Features:
1. Cummins industrial diesel engine
2. Radiator 40°C max,fans are driven by belt, with safety guard
3. Choice of manual/auto and AMF control panels and protection systems
4. Digital auto-start panel
5. Anti Vibration Suspension Absorber
6. Dry type air filter, fuel filter, oil filter
7. Mould case circuit breaker
8. 24V DC start motor and storage battery
9. Ripple flex exhaust pipe, exhaust siphon, flange, and muffler
