Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1000 watt
Supply Capability:20000000 watt/month
1.Structure of Solar Module Description
Solar Polycrystalline 156mm Series (160W-----200W)
2.Characteristics of the Solar Module
| Max Power Voltage Vmp (V) | 35.6 | 35.8 | 35.8 | 35.6 | 36.0 |
| Max Power Current Imp (A) | 4.50 | 4.75 | 4.75 | 5.06 | 5.56 |
| Open Circuit Voltage Voc (V) | 43.4 | 43.6 | 43.4 | 43.4 | 44.0 |
| Short Circuit Current Isc (A) | 4.82 | 5.16 | 5.41 | 5.41 | 5.95 |
| Max Power Pm(W) | 160 | 170 | 180 | 190 | 200 |
3.Limits of the Solar Module
Operating Temperature ﹣40℃to+85℃
Storage Temperature ﹣40℃to+85℃
Max System Voltage 700V
4.Specifications of the Solar Module
| Power | 160W/170W | 180W/190W/200W |
| Dimension | 1200x992x35mm | 1330x992x35mm |
| Weight | 14.6kg | 16.2kg |
| Tolerance | ±3％ | ±3％ |
The dimension of the modules can be changed according to the demand of clients
5.Guarantee of the Solar Module
| Products Guarantee | 2 yrs free from defects in materials and
workmanship |
| Performance Guarantee | No less than 90％ within 10yrs and no less than 80％ within 20yrs |
| Certificates | IEC,ISO,TUV,CE |
6.Applications of the Solar Module
1.Electricity
2.Heat energy
7.IMages of the Solar Module
FAQ
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Jiangyin city, jiangsu province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Do you provide free sample?
A: Usually we do not offer free sample
4. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
