Loading Port:Shanghai
Payment Terms:TT or LC
Min Order Qty:1 PCS
Supply Capability:100000 PCS/month
Description:
CNBM Solar is a world-leading and Vertical integrated manufacturer of high-performance with Silicon,
Wafer, Cells, Modules, which convert sunlight into electricity for residential, commercial, and utility-scale
power generation.
The capacity of CNBMSolar is reach to 1GW, and make sure each year our shipment capacity is more
Than 700-800MWs, at the same time, we have set up the largest solar power station with our partner
in Ukraine.
CNBM is a Quality + Service oriented company with“Excellence at Each Step” approach, composed of
the finest components from TUV and IEC-certified partners around the world, CNBM modules consistently
undergo a variety of trials at the company’s Test & Development Centre, ensuring peak performance
capabilities. The company is committed to develop and provide the world with clean and renewable energy
to ease the energy shortages as well as human kind’s impact on the environment.
PERFORMANCE
- High effi ciency, multicrystalline silicon solar cells with high transmission
and textured glass deliver a module effi ciency of up to 16.0%,
minimizing installation costs and maximizing the kWh output of your
system per unit area.
- Tight positive power tolerance of 0W to +5W ensures you receive
modules at or above nameplate power and contributes to minimizing
module mismatch losses leading to improved system yield.
- Top ranking in the “TÜV Rheinland Energy Yield Test” and the
“PHOTON Test” demonstrates high performance and annual energy
production.
RELIABILITY
- Tests by independent laboratories prove that modules:
Fully conform to certifi cation and regulatory standards.
Withstand wind loads of up to 2.4kPa and snow loads of up to
5.4kPa, confi rming mechanical stability.
Successfully endure ammonia and salt-mist exposure at the highest
severity level, ensuring their performance in adverse conditions.
- Manufacturing facility certifi ed by TÜV Rheinland to ISO 9001:2008,
ISO 14001:2004 and BS OHSAS 18001:2007.
WARRANTIES
- 10-year limited product warranty1.
- Limited power warranty1: 10 years at 91.2% of the minimal rated power
output, 25 years at 80.7% of the minimal rated power output.
1In compliance with our Warranty Terms and Conditions.
QUALIFICATIONS & CERTIFICATES
IEC 61215, IEC 61730, MCS, CE, ISO 9001:2008, ISO 14001:2004, BS OHSAS
18001:2007, PV Cycle, SA 8000
ELECTRICAL PERFORMANCE
Electrical parameters at Standard Test Conditions (STC)
| Electrical parameters at Standard Test Conditions (STC) | |||
| Power output | P max | W | 250 |
| Power output tolerances | ΔP max | W | 0 / + 5 |
| Module effi ciency | η m | % | 15.4 |
| Voltage at Pmax | V mpp | V | 29.8 |
| Current at Pmax | I mpp | A | 8.39 |
| Open-circuit voltage | V oc | V | 37.6 |
| Short-circuit current | I sc | A | 8.92 |
| Electrical parameters at Nominal Operating Cell Temperature (NOCT) | |||||||
| Power output | P max | W | 189.7 | 186 | 182.4 | 178.7 | 175.1 |
| Voltage at Pmax | V mpp | V | 27.6 | 27.4 | 27.2 | 27 | 26.8 |
| Current at Pmax | I mpp | A | 6.87 | 6.79 | 6.71 | 6.62 | 6.54 |
| Open-circuit voltage | V oc | V | 34.8 | 34.8 | 34.7 | 34.6 | 34.6 |
| Short-circuit current | I sc | A | 7.35 | 7.28 | 7.21 | 7.14 | 7.07 |
FAQ: What is your warranty system?
For c-Si panel: 25years output warranty for no less than 80% of performance, 10years output warranty for no less than 90% of performance. Free from material and workmanship defects within 5years.
For a-Si panel: 20years output warranty for no less than 80% of performance, 10years output warranty for no less than 90% of performance. Free from material and workmanship defects within 2years.
