FTC Solar Panels (100W Poly) with TUV Certification in China

Product Description:

 Mechanical Characteristics

Max-power Pm(W)                                           140

Max-power voltage Vmp(V)                            17.2

Max-power current Imp(A)                               5.82

Open-circuit voltage Voc(V)                            21.7

Short-circuit current Isc(A)                               6.61

Dimension(mm)                                     12520*670*30

Weight(kg)                                                         9.5

Operating Conditions

Operating Temperature                              -40~85°c

Storage Temperature                                 -40~85°c

Maximum system voltage                         DC 1000V

Temperature and Coefficients

NOCT                                                             48± 2°c

Temperature coefficient of Voc(%/K)         -0.34

Temperature coefficient of Isc(%/K)           0.09

Power temperature coefficient(%/K)         -0.37

Quality and Safety

1. Rigorous quality control meets the highest international standards.

2. High-transmissivity low-iron tempered glass, strong aluminium frame.

3. Using UV-resistant silicon.

4. IS09001/14001/CE/TUV/UL

Package Picture

FAQ

I. Will you focus on the safety of the goods during transportation?

Yes, Safety of the cargo is the primary element that we would consider on transportation.

II..How would guarantee the quality will meet the requirements of your clients?

Before shipment, we will have inspection for each batch of goods.

III..What certificates do you have?

IEC,UL,TUV,CSA,etc.

IV..Can you do OEM according to clients’ requirements?

Yes, we have our own brand while we can provide OEM service.
