Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Model NO.:800D
Type:Skid Steer Loader
Walking Mode:Wheeled
Certification:CE, ISO9001: 2000
Condition:New
Color:White
Engine Model:Xinchai A498bpg
Export Markets:Global
Trademark:WECAN
Packing:Nude Package; 2PCS/20CTN
Standard:CE, ISO9001
Origin:Shandong, China
HS Code:8429510000
Production Capacity:600PCS/Year
800D Skid Steer Loader with CE& ISO 9001
1)China Engine
2)Original Imported Sauel Pump
3)Mechanical AUTO Leveling
4)SPECIAL Big Aluminium Radiator
5)Original Imported Sauel Motor
| Model Item | 800D | Model Major | 800D |
| Engine model | Xinchai A498 | Overall operating height (mm) | 3850 |
| Bore×stroke (mm) | 98×105 | Height to bucket hinge pin (mm) | 3225 |
| Rated power (kw) | 45 | Height to top of cab (mm) | 2070 |
| Rotating speed (rpm) | 2500 | Height to bottom of level bucket(mm) | 3065 |
| Number of cylinders | 4 | Overall length without bucket (mm) | 2538 |
| Max. Torque (n.m) | 193 | Overall length with bucket (mm) | 3345 |
| Displacement (L) | 3.168 | Dumping angle at maximum height (°) | 42 |
| Max. Speed (km) | 11.2 | Dumping height (mm) | 2445 |
| Vacuum tire | 10-16.5 | Dumping reach (mm) | 585 |
| Operating load (kg) | 800 | Rollback of bucket on ground (°) | 31 |
| Max. Loading (kg) | 1400 | Rollback of bucket at full height (°) | 86 |
| Lifting | Radial | Wheelbase (mm) | 991 |
| Bucket lifting force (kN) | 15 | Ground clearance (mm) | 210 |
| Arm lifting force (kN) | 13 | Angle of departure (°) | 30 |
| Total cycling time(s) | 10.2 | Turning radius front without bucket (mm) | 1380 |
| Bucket capacity (m³) | 0.47 | Front turning radius (mm) | 2027 |
| Pressure of working system (bar) | 160 | Rear turning radius (mm) | 1527 |
| Rated flux(L/min) | 63 | Rear axle to bumper (mm) | 981 |
| High flow flux (L/min) (optional) | --- | Tread width, centerline to centerline (mm) | 1465 |
| Fuel tank capacity(L) | 79 | Width between outside of two wheels (mm) | 1730 |
| Self-weight with bucket (kg) | 2920 | Bucket width (mm) | 1800 |
