Signcomplex Ce Rohs Smd5050 Led Rigid Strip Light, Led Bar, 12V Led Light Bar, Led Rigid Bar

Product Description:

‍General Introduction

High quality flexible led strip,Flexmond3020 high brightness ,It is the brightest flexible LED strip available in the market.

Application

-Cove lighting
-Architectural lights for canopy,corridor,window,archway
-Backlight or edge lighting for signage
-DIY lights for home use
-Path and contour marking
-Decorative lights for holiday,event,show,exhibition

Available models:

3528 60leds/m ,120leds/m,240leds/m.

5050 30leds/m. 60leds/m.

Super bright 3020 120leds/m.

Super bright 3014 60leds/m,120leds/m,204leds/m.

WW+W CCT dimmable models.

RGB+W changeable models.

Digital striplight models.

Rigid Waterproof LED Strips

1. standard lengths 50cm and 100cm.
2. Compact size compatible with confined spaces.
3. More brightness brings light flood effect.

4. Easy connection and installation. No extra extrusion or front cover needed.

5. Low temperature maintained.

6. Low power consumption.

Assembly Information

- Solder connection should only be performed on designated solder pads(marked +/-).During soldering,don’t exceed the
maximum soldering time of 10 seconds and the maximum soldering temperature of 260 Celsius degrees.

- The smallest unit(25mm/1 -3 LEDs) can be removed by cutting with scissors between the designated solder pads.

- The mounting of the strip is facilitaed by means of the double-sided adhesive on the back-surface of the strip.Care must be
taken to provide a clean and dry mounting surface,free of oils or silicone coatings as well as dirt partide.The mounting substrate
must have sufficient structural integrity.Take care to completely remove the adhesive backing.Once the strip is appropriately
positioned.Press on the strip with about 20N/cm2(refer to application techniques of 3M adhesive transfer tapes).

- The minimum bending radius is 2 cm. The strip may be bent over a smaller radius of the circuit board containing no electronic

- components and  bends should be made once and fixed in position to avoid cyclic fatigue.

Packaging & Delivery

Package:

1 x Brown Carton

Delivery:

1. 3-10 business days for Sample Orders; 7-40 business days for Bulk Orders.

2. "Business days" means Monday-Friday, excluding holidays.

3. DHL and UPS cannot ship to military or P.O. boxes address.

4. The Shipping Service above is for reference only, for any other questions, please feel free to contact us.
