Loading Port:Qingdao
Payment Terms:TT OR LC
Min Order Qty:10 m.t
Supply Capability:500000 m.t/month
Specifications of Green silicon carbide(F20-240):
SiC: 98.5%
MI:F 8-70 0.03%max,F 80-240 0.02%max
LPD: 1.37-1.50
used in grinding, abrasive
- Description:
It is produced in electric resistance furnace from quartz sand, petroleum coke and salt in high temperature. Its semi-transparent in green color with crystal structure, high hardness and strong cutting ability, stable chemical characteristics, good thermal conductivity.
- Applications:
♦Abrasive
♦Blasting
♦Coatings
♦Polishing
♦Vitrified and Resinoid Grinding Wheels
- Physical Properties:
Color : Green
Shape : Angular
Crystal Form Alpha silicon carbide in hexagonal system
Specific Gravity : 3.20
Hardness : HV3280-3400, 9.15 Mohs scale
- Specification:
SIZE | SIC | F.C | FE2O3 |
F24-90 | 99.00%min | 0.20%max | 0.20%max |
F100-150 | 98.50%min | 0.25%max | 0.50max |
F180-240 | 97.50%min | 0.25%max | 0.70max |
SIZE | M.I. |
F16-70 | 0.03%max |
F80-240 | 0.02%max |
SIZE | BULK DENSITY | HIGH BULK DENSITY |
F16-24 | 1.38-1.46 | ≥1.46 |
F30-40 | 1.41-1.49 | ≥1.49 |
F46-54 | 1.40-1.48 | ≥1.48 |
F60-70 | 1.40-1.48 | ≥1.48 |
F80 | 1.38-1.46 | ≥1.46 |
F90 | 1.37-1.45 | ≥1.45 |
F100 | 1.37-1.45 | ≥1.45 |
F120 | 1.35-1.43 | ≥1.43 |
F150 | 1.31-1.41 | ≥1.41 |
F180 | 1.28-1.38 | ≥1.38 |
F220 | 1.26-1.36 | ≥1.36 |
F240 | 1.26-1.35 | ≥1.35 |
