Sharp Chip 2Pin/3Pin/4Pin Cob Led Track Light,30W Dimmable Led Track Light

Loading Port:Shenzhen

Payment Terms:L/C,T/T

Min Order Qty:1 Piece pc

Supply Capability:5000 Pieces pc/month

Product Description:

Features:

1. Advanced constant current driver.
2. Professional thermal management.
3. Instant on, no warm up time required.
4. No noise, no flickering.
5. No UV or IR radiation in the beam, mercury free.
6. Anti-shock, anti-moisture.
7. Long lifespan, higher than 50,000H.



Specification:

Name

COB LED TRACK LIGHT

item

Parameter

LED Brand

Sharp/Epistar 45mil COB led

power

30W

IP code

IP44

Safety class

CLII [Safety class II]

Life Span

50,000 hours a t 25ºC,(70% lumens at 35000hr)

warranty

3 years

Mounting

if 3 circuit track

On 3-circuit track (3C or 3 phase)

if 2 circuit track such as halo

On 2-circuit track (2C or 3 lines)

Electrical Characteristics

power of led module

Voltage

AC85-265V

Line Frequency

50-60 Hz

Lamp Current mA

1050mA

Operating temperature range

-20 to +50ºC

Transformer/ power supply unit

driver built-in

Light Technical Characteristics

Color Tempreture(CCT.)

WW 3000-3200K, DW: 4000-4200K, PW: 5000-5200K, CW: 6000-6500K

Beam Angle

25/45/60°

Luminous Flux

90-100lm/W

Color rendering index

>80Ra

Accessories

track Rail, track rail connector



Advantages:

The material of our products are high quality.





Products list



NO.

Item No.

track 2line

Size (mm)

Power

lumen

Vol.

65

TL2301

2line/3line/4line

D60*112*165

7W

600-700

AC100-240V

66

TL2304

2line/3line/4line

D*H:90*150

20W

1800-2000

AC100-240V

67

TL2304A

2line/3line/4line

D*H:90*150

30W

2700-3000

AC100-240V

68

TL2305

2line/3line/4line

D*H:105*165

20w

1800-2000

AC100-240V

69

TL2305A

2line/3line/4line

D*H:105*165

30w

2700-3000

AC100-240V

70

TL2303

2line/3line/4line

D*H:108*155

30W

2700-3000

AC100-240V

71

TL2302

2line/3line/4line

D*H 100*160

40W

3600-3900

AC100-240V

72

TL2306

2line/3line/4line

D*H 126*160

50W

4500-4900

AC100-240V





Advantage:

1. High Integrated Luminous Efficiency.

2. High Safety Factor.

3. High power factor,

4. Perfect heat dissipation and long lifespan.

5. Own our independent intellectual property rights.

6. High-class design





Application:

1. Replacement for conventional halogen track light;

2. Shopping mall or retailing store, jewellery and clothing display;

3. Museum or art gallery, exhibition hall and other partial lighting;

4. Commercial complex, supermarket, hotel, restaurant, bar, disco, karaoke lighting;

5. Conference, meeting room, showroom, showcase, etc.



Our service:

1,OEM&ODM welcomed,also provide customized service

2,All your inquireies will be well explained by our experienced staff

3,Your inquirey related to our products or price will be replied within 24 hours

4,Distributorship is available for your unique design and some our current models
