Sealing Machine and Plastic Tube Filling Zhy-60yp

Loading Port:Shanghai

Payment Terms:TT or LC

Min Order Qty:1 unit

Supply Capability:2500 unit/month

Product Description:

 Sealing Machine and Plastic Tube Filling (Zhy-60yp)

Product Details

Basic Info.

Model NO.:ZHY-60YP



Packaging Type:Tube

Automatic Grade:Automatic



Packaging Material:Plastic

Application:Cosmetics, Cleaning, Detergent, Skin Care Products, Hair Care Products



Type:Filling and Sealing Machine

Packaging Material Mechanical Properties:Full Automatic Filling and Sealing Machine



Material Type:Bulk Solid

Dimension:1950× 760× 1850(Mm)



Export Markets:Global

Additional Info.

Trademark:ZHONGHUAN



Packing:Wood

Origin:Wenzhou Zhejiang China



HS Code:8421219090

Production Capacity:100set/Year

Product Description

Plastic Tube Filling and Sealing Machine ZHY-60YP

Model: ZHY-60YP
Key Features
Compact Design
Driving Parts Fully-closed
Pneumatic Tube Washing & Feeding
Intelligent Temperature Control and Cooling System
Easy to Operate and Adjust
316L Stainless Steel Contact Parts to meet GMP Standard
Safety Interlock Shutdown when Door is Open
Overload Protection Provided
Automated Working process from Tube Loading to Finished Products Output
Automatic Orientation Effected by Photoelectric Induction

Optional Devices
Chiller
Date Coding Embossing
Automatic Tube Feeding Magazine
Change Parts

Technical Parameters
Filling volume: 1-250ml/unit (Adjustable)
Filling accuracy: ≤ ± 1
Capacity: 1800-3600unit/hour, Adjustable
Tube diameter: Φ 10-50 mm
Tube length: 50-200mm
Hopper volume: 40L
Power: 380V/220V (Optional)
Air pressure: 0.4-0.6 MPa
Equipped motor: 1.1KW
Machine power: 5kw
Inner wind motor: 0.37kw
Convulsions motor: 0.37kw
Dimension: 1950× 760× 1850(mm)
Weight: About 950 Kg

Filling volume1-250ml/unit (Adjustable)
Filling accuracy≤ ± 1
Capacity1800-3600unit/hour, Adjustable
Tube diameterΦ 10-50 mm
Tube length50-200mm
Hopper volume40L
Power380V/220V (Optional)
Air pressure0.4-0.6 MPa
Equipped motor1.1KW
Machine power5kw
Inner wind motor0.37kw
Convulsions motor0.37kw
Dimension1950× 760× 1850(mm)
WeightAbout 950 Kg

Sealing Machine and Plastic Tube Filling  Zhy-60yp

Sealing Machine and Plastic Tube Filling  Zhy-60yp




Tube filling and sealing machine transmission part of its closed below platform, safe and reliable, no pollution;Sealing parts installed on the platform above the casing outside the semi-closed no static visual enclosure, easy observation, easy operation, easy maintenance.His main purpose and performance for PLC control, man-machine dialogue interface;Wide rotary table driven by CAM, fast speed, high precision;Hang on type pipe, the pipe body is equipped with a vacuum adsorption device, ensure accurate automatic tube into the tube;Photoelectric for standard workstation, with high-precision sensor, stepper motor control such as tube pattern in the correct position;Filling nozzle is equipped with cutting mechanism, ensure the quality of filling;No tube no filling;Sealing using (Leister hot air gun) tube tail internal heat, external cooling device;Play word workstation automatically word printed in the position of the technological requirements;Right angles to the plastic mechanical shear hose tail or rounded corners to choose;Failure to protect police, without alarm, door key, overload downtime;Count and quantitative downtime.
