Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
| Model | ESJY-1-4.5 | ESJY-1-6 | ESJY-1-9 | ESJY-1-12 | |
| Capacity | KGS | 1000 | |||
| Max height | 4500 | 6000 | 9000 | 12000 | |
| Min height | 1120 | 1460 | 1750 | 1860 | |
| Platform size | 1500*880 | 1800*1000 | 2000*1200 | 2500*1500 | |
| Scissor material | 150*50*5 | 150*50*5 | 150*50*5 | 160*60*6 | |
| Wheel pump | CB-E304 | CB-E306 | CB-E306 | CB-E308 | |
| Tyre | 400-8 | 500-8 | 500-8 | 600-9 | |
| Oil pump | D80*2 | D100*2 | D100*3 | D100*4 | |
| Overall length | 1600 | 1950 | 2150 | 2650 | |
| Overall width | 1080 | 1200 | 1400 | 1700 | |
| Overall height （rail fold） | 1270 | 1610 | 1900 | 2010 | |
| Rail height | mm | 1000 | |||
| Overall weight | kg | 800 | 1400 | 2000 | 3000 |
| Lift/Fall speed | s | 50 | 90 | 90 | 125 |
| Min turn radius | m | 5.5 | 6 | 8 | 11 |
| Extended platform size | mm | 700 | 800 | 800 | / |
| Battery | 120Ah*2 | 150Ah*2 | 200Ah*2 | 150Ah*4 | |
| Charger | DC24V20A | DC24V20A | DC24V30A | DC48V20A | |
| Hydraulic | cc/r | 2cc/r | 2.5cc/r | 2.5cc/r | 2.5cc/r |
| Lift motor | DC24V2.2kw 2800r/min | DC24V3kw 2800r/min | DC24V3kw 2800r/min | DC48V3kw 2800r/min | |
| Drive motor | 750WDC24V | 750WDC24V | 1000WDC24V | 1200WDC48V | |
| Controller | Curtis | ||||
| Travel speed | KM/h | 4 | |||
| Gradeability | % | 13% | 13% | 10% | 10% |
It can be ordered according to your requipments.
