Loading Port:Qingdao
Payment Terms:TT or LC
Min Order Qty:10 m
Supply Capability:10000 m/month
Product Description:
Rubber Hose Without Flange normally made by rubber material according to customer’s requests, and also package in bundles or nude packing directly put into container.
Black EPDM/SBR blended compound
Inner layer:
1.material:NR/SBR/BR/NBR/EPDM
2. feature:Air tightness and good resistance to buckling,smoothing, anti-bending, antil-elongating and anti-aging
Framework: employing fine fabric (canvas) or chemical fabric cloth.
Outer layer:
1.material: NR/SBR/BR/NBR/EPDM
2. feature:The tube body is light, Anti-bending of aging, ozone resistance, toughness and wear resistance Visual effect is good
Suitable temperature:-40 ~ +90 °C
Scope of Application of the pipes
Rubber Hose is a concrete delivery for combined use with other concrete pipelines in concrete placement operations. It can be widely used in the construction of various types of concrete structures like industrial and civil buildings, bridges, roads, and other types of infrastructure.
It is used for the suction of normal temperature water & neutual liquid in the project of industrial mining, civil engineering and hydro project the hose is also not allowed to be used in any location where any combustible or explosive material exists or a cave-in may occur.
Product Advantages:
OKorder's Hose Without Flange Channels are durable, strong, and safety.
Main Product Features:
· Premium quality
· Prompt delivery & seaworthy packing (5-10 days)
Reliable performance
Easy to weld
High safety.
· Professional Service
· Competitive pricing
Measuring of wall thickness from the outside
Low purchase cost
FAQ:
Q1: How long about delivery time?
A1: Normally we keep the raw materials for old customers and sometime we also keep stock products to make sure delivery time in any emergency cases.
Q2: How do we guarantee the quality of our pipes?
A2: We have established an advanced quality management system which conducts strict quality tests at every step, from raw materials to the final product. At the same time, we provide extensive follow-up service assurances as required.
Q3: How soon can we receive the product after purchase?
A3: Within three days of placing an order, we will book the vessel for goods. The specific shipping date is dependent upon international and government factors, but is typically 7 to 30 workdays.
Q4: If we can produce some pipes according to customers request?
A4: Yes, we can produce Concrete Placing Boom according to the difference country situations to make it suitable to the market and customers. We have very professional technical team to make the design.
Q5: How to make a quick resolution for after service?
A5: OKorder and our manufacture both have overseas branches all-around of world, IF needed,
Technology parameters
Inner diameter I.D. | Working pressure W.P. | Blasting pressure B.P. | Weight Kg/M | |||
mm | inch | Psi | Mpa | Psi | Mpa | |
8 | 5/16 | 42~170 | 0.3~1.2 | 126~510 | 0.9~3.6 | 0.23 |
9.5(10) | 3/8 | 42~170 | 0.3~1.2 | 126~510 | 0.9~3.6 | 0.26 |
13(12.7) | 1/2 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 0.36 |
16 | 5/8 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 0.53 |
19 | 3/4 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 0.64 |
25 | 1 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 0.85 |
32 | 11/4 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 1.20 |
38 | 11/2 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 1.39 |
45 | 13/4 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 1.62 |
51 | 2 | 42~114 | 0.3~0.8 | 126~340 | 0.9~2.4 | 1.80 |
58 | 23/8 | 28~114 | 0.2~0.8 | 85~340 | 0.6~2.4 | 1.85 |
64 | 21/2 | 28~114 | 0.2~0.8 | 85~340 | 0.6~2.4 | 2.02 |
76 | 3 | 28~114 | 0.2~0.8 | 85~340 | 0.6~2.4 | 2.41 |
89 | 31/2 | 28~114 | 0.2~0.8 | 85~340 | 0.6~2.4 | 2.78 |
102 | 4 | 28~70 | 0.2-0.5 | 85~200 | 0.6~1.5 | 3.16 |
127 | 5 | 28~70 | 0.2-0.5 | 85~200 | 0.6~1.5 | 3.87 |
152 | 6 | 28~70 | 0.2-0.5 | 85~200 | 0.6~1.5 | 5.13 |
178 | 7 | 28~70 | 0.2-0.5 | 85~200 | 0.6~1.5 | 6.15 |
203 | 8 | 28~42 | 0.2~0.3 | 85~126 | 0.6~0.9 | 6.97 |
254 | 10 | 28~42 | 0.2~0.3 | 85~126 | 0.6~0.9 | 9.78 |
305 | 12 | 28~42 | 0.2~0.3 | 85~126 | 0.6~0.9 | 13.03 |
457 | 18 | 28~42 | 0.2~0.3 | 85~126 | 0.6~0.9 | 24.28 |
Note: 1.The weights above are all theoretical values, and the actual
weight needs to be re-determined as the customer’s requirement.
2.Requirements for special working pressure, length, or colors
may be satisfied according to orders.
3.We can product the size(inner diameter)of you need,it
include:3/4,1,1-1/4,1-1/2,1-3/4,2,2-3/8,2-1/2,3,3-1/2,4,5,6,7,8,10,12,18 ect.
