Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1000 PCS/month
Road Roller Mechanical Drive Hh220b
Model NO.:HH220B
Type:Road Roller
Object:Soil Surface
Asphalt Distributor Type:Rubber Asphalt Distributor
Marking Vehicle Type:Hot Melt Marking Vehicle
Moving Type:Mobile
Mixing Method:Intermittent Compulsory
Automatic Grade:Automatic
Product Capacity:>400t/h
Certification:ISO9001: 2000, CE
Condition:New
Operating Weight(Kg):20000
Grade Ability(%):35
Weight Burden on Front Drum(Kg):10000
Weight Burden on Rear Wheel(Kg):10000
Static Linear Load (N/Cm):460
Travel Speed(Km/H):2.0/4.0/10.5
Export Markets:Global
Trademark:CHHGC
Packing:Standard Export Packing
Standard:5820x2280x3000MM
Origin:China
HS Code:8429401900
Production Capacity:5000units / 500 Unit/Units Per Month
--Specification:
112 months warranty
2.Free spare parts within warranty
3.ISO CE certificate.
--Main features:
1.Mechanical drive, hydraulic vibration and steering, dual amplitude
2. Special gearbox and driving axle,
3. Vibratory system adopt gear pump and motor of joint-ventures.
4. Cabin with UV resistence glass and anti-roll structure
5. Compaction testing meter, air-condition, padfoot or removal padfoot as options
--Main techical parameters:
Specifications \ Item NO. | HH216B | HH218B | HH220B |
Operating weight(kg) | 16000 | 18000 | 20000 |
Length x Width x Height(mm) | 5820x2278x3000 | 5820x2280x3000 | 5820x2280x3000 |
Weight burden on front drum(kg) | 8000 | 9000 | 10000 |
Weight burden on rear wheel(kg) | 8000 | 9000 | 10000 |
Static linear load (N/cm) | 378 | 415 | 460 |
Min. turning radius(mm) | 7500 | 7500 | 7500 |
Travel speed(km/h) | 2.0/4.0/10.5 | 2.0/4.0/10.5 | 2.0/4.0/10.5 |
Grade ability(%) | 35 | 35 | 35 |
Vilibration frequency (Hz) | 30 | 30 | 30 |
Nominal amplitude (mm) | 2.0/1.0 | 2.0/1.0 | 2.0/1.0 |
Centrifugal force(kN) | 320/180 | 340/200 | 360/220 |
Engine model | YC6108ZG | D6114ZG(Shang Chai) | D6114ZG |
Min. fuel consumption(g/km h) | 210 | 200 | 200 |
Rated power(kw)/RPM(r/min) | 105/2000 | 132/2000 | 132/2000 |
Fuel tank capacity (L) | 180 | 180 | 180 |
Vibration pump | Permco | Permco | Permco |
Vibration motor | Permco | Permco | Permco |
Steering model | Hydraulic | Hydraulic | Hydraulic |
Axle type | PR75.-27 | PR75.-27 | PR75.-27 |
Tyre | 23.1-26 | 23.1-26 | 23.1-26 |
Service brake type | caliper brake(gas pushed oin assistance) | caliper brake(gas pushed oin assistance) | caliper brake(gas pushed oin assistance) |
Parking brake type | hand brake( drum brake) | hand brake( drum brake) | hand brake( drum brake) |
Hydraulic oil tank capacity (L) | 150 | 150 | 150 |
A/C Model | |||
A/C Refrigerating capacity (W) | 400 | 400 | 400 |
A/C Heating capacity (W) | 100 | 100 | 100 |
