Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:5 m.t
Supply Capability:10000 m.t/month
1.Structure of Refrigeration Aluminum Condenser Coil Description：
They are widely used in construction and decoration, hardware and electric appliances manufacture,
automobile manufacture and other industrial and civil purposes, such as electronic capacitor, rice
cooker, refrigerator, computer casting, lamp shade, air-conditioner, cosmetics cover and box, air-
conditioner radiator, inner container of disinfecting cabinet, ceiling board, automobile motherboard,
cover board and top board, etc.
1). The heat exchangers have a wide rang of plications such as: Window, Split and package AC systems;
2). Commercial Refrigeration Systems (Kitchen refrigerator, bottle cooler, deep freezer, milk tank, etc);
3). Industrial Refrigeration Systems (Printing machine, Colling machine, etc);
4). Automobile-Buses / Car air conditioning;
5). Railway air-conditioning an Marine air-conditioning;
6). Special Application Coils.
4. Refrigeration Aluminum Condenser Coil Specification:
| Fin Pattern | Copper Tube O. D. (mm) | Row Space(mm) | Hole Space(mm) | Fin Thickness(mm) | Fin Space(mm) | ||||
| Flat fin | Sine wave with blade fin | Smooth sine wave fin | Window fin | Sesamoid fin | |||||
| A | 7 | 12.7 | 21 | 0.105 | / | / | 1.3 | 1.3 | / |
| B | 7 | 13.2 | 17.6 | 0.105 | / | / | 1.3 | 1.3 | / |
| C | 7 | 12.7 | 20.4 | 0.105 | / | / | 1.3~1.8 | 1.3~1.8 | / |
| D | 7.94 | 15.88 | 25.4 | 0.105 | 1.8~3.0 | 1.8~3.0 | 1.8~3.0 | 1.8~3.0 | / |
| E | 9.52 | 22 | 25.4 | 0.105~0.15 | 1.6~3.2 | 1.6~3.2 | 1.6~3.2 | 1.6~3.2 | / |
| F | 9.52 | 22 | 25.4 | 0.18~0.4 | 3.5~6.35 | / | / | / | / |
| G | 9.52 | 21.65 | 25 | 0.105~0.18 | 1.6~3.2 | 1.6~3.2 | 1.6~3.2 | 1.6~3.2 | / |
| H | 9.52 | 21.65 | 25 | 0.15~0.24 | 3.2~6.35 | 3.2~6.35 | 3.2~6.35 | / | / |
| I | 12.75 | 27.5 | 31.75 | 0.115~0.15 | 1.5~3.5 | 1.5~3.5 | 1.5~3.5 | 1.5~3.5 | 1.6~3.2 |
| J | 15.88 | 33 | 38.1 | 0.115~0.15 | 1.5~4.0 | 1.5~4.0 | 1.5~4.0 | / | / |
| K | 15.88 | 34.64 | 40 | 0.115~0.15 | / | 2.6~3.5 | 2.6~3.5 | / | / |
Q1.How long have you been in this product?
A1:More than 10 years.
Q2. What's the minium quantity(MOQ)?
A2. 5 Metric tons
Q3. How long is shipping time?
A3. 7 (ready-made products)-25 days(OEM)
Q4. How do you guarantee the quality?
A4. 1. Cooperating and Exchaning experience with sevral quoted aluminum companies
2. Japanese and Swiss production line and skilled works (regular training and testing)
3. more than 10 years production experience.
Q5. Do you have after sale service?
A5. Yes. Any quality problem occurs within one year, pls take photoes,we will be responsible.
