Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:10 m.t.
Supply Capability:100 m.t./month
| Application: | Liners Of Industrial Furnace | Grade: | HAZ (High Aluminum Zirconium) | Working Temperature: | 900-1700 Celsius |
| Place of Origin: | (Mainland) | Model Number: | TZ-1000/1260/1430/1600/1700/1800 | Brand Name: | |
| Length: | 900mm or customized | Thickness: | customized | Width: | 600mm or customized |
| Packaging Detail: | Packaged in wooden box with polyfoam and plastic paper. |
| Delivery Detail: | 10 days |
Ceramic Fiber Board:
Size is customized;
Code:1000/1260/1430/1600/1700/1800;
Working temperature 900-1700 Deg.;
1600 Heat Resistant Ceramic Fiber Board
Introduction
CERAMIC FIBER BOARD is made of high purity alumina fibrous and alumina powder,to be formed and fired in special equipment with advanced patent process,can withstand temperature up to 1700 celsius.
Features:
1. Low thermal conductivity
2. High compression strength.
3. Long service life.
4. Good thermal shock resistance and good toughness.
5. Flexible and tearing resistance.
6. Easy to cut and operate.
6.Good electric and sound insulation.
7.Good mechanical working performance.
Product Types:
| Type | TZ-1000 | TZ-1260 | TZ-1400 | TZ-1600 | TZ-1700 | TZ-1800 |
| Classification temperature | 1000 | 1260 | 1400 | 1600 | 1700 | 1800 |
| density (Kg/m3 | 200-600 | 200-600 | 200-600 | 200-600 | 350-600 | 350-600 |
| Line change (.CX24hS) | 1.3 (900.C) | 1.1 (1100.C) | 1.6 (1200.C) | <2.0 (1400.C) | <2.0 (1500.C) | <2.0 (1600.C) |
| compressive strength | 0.5 | 0.5 | 0.5 | 0.3 | 0.3 | 0.3 |
Physical Character:
| Density(Kg/m3) | 400 | |
| Strength to resist bending(MPa,25.C) | 0.72 | |
| Linear shrinkage rate % (1600 .Cx8hrs) | 0.13(1.7) | |
| Expansion rate at %(600.C) | 0.28 | |
| Average modulus of linear expansion (x10-6/K) | 1.77 | |
| Thermal conductivity rate GHP[W/(mK)] | 400.C | 0.147 |
| 600.C | 0.186 | |
| 800.C | 0.236 | |
| 1000.C | 0.296 | |
| Chemical composition | AL2O3:87% SiO2:13% | |
Standard Size:
25x600x900mm
40x600x900mm
30x600x900mm
50x600x900mm
100x600x900mm
Application:
| Character | Product Applying |
| High-temperature steady | Verity high-temperature industrial furnace backing heat insulation |
| low heat conductivity | Ceramics kiln, mechanic and metallurgy heating furnace, thermal treatment furnace and others industrial furnace and hot face internal lining Low heating quantity High-temperature block-fire and flame-insulated |
| easy-mechanic processing | Kiln door, kiln car and dilatation joint etc insulation material |
| Tidy surface | Glass kiln insulation |
