Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 pc
Supply Capability:1000 pc/month
Product Description
Application:
All kinds of home appliance, office equipment, solar power system, and other equipments which use single phase power.
Features:
Pure sine wave output, available for sensitive load
4-step progressive charging, 7 battery type selector
Fast and powerful charger with 35A and 70A
Accept generator's energy output
High power factor
Automatically transfer between battery and line modes
Microprocessor control guarantees high reliability
Bypass without battery connected
Remote control function
Protection against:
Over load, over temperature, over charging, low battery
Reverse connection(optional by hard connector)
Blackouts
| 7-LED Display | From the right to the left, LED1 line mode (green lighting), LED2 inverter mode | |||||
| (green lighting), LED3 charging mode(yellow lighting), LED4 Fully charged | ||||||
| (green lighting), LED5 over heat shutdown(red lighting), LED6 Overloaded | ||||||
| shutdown(red lighting), LED7 Saving Mode(green lighting) | ||||||
| 3-LED Display | Charging Mode(green lighting), inverter mode(green lighting), Alarm(red lighting) | |||||
| Switch selector | Saving Mode is on/off when push the switch forwards/backwards, keeping it horisontal is | |||||
| turning the inverter off. | ||||||
| Audible Alarm | Sounding when the heatsink' s tem is over 105° C and shutdown after 30 seconds. | |||||
| Protections | low battery, over charging, over temp, over load | |||||
| Communications | RS-232/USB(custom-made) | |||||
| Enviromental | ||||||
| Operating Environment | 0-40° C, 0-90%RH(non-condensing) | |||||
| Audible Noise | < 60dB | |||||
| Physical | ||||||
| Net Weight(KG) | 18 | 20 | 22 | 35 | 38 | 40 |
| Dimension, D X W X H(mm) | 218X179X442 | 218X179X598 | ||||
