Prepainted Steel coils, Hot-dipped Galvanized, with good corrosion resistance

Product Description:

Specifications

T:0.16~1.2mm
Z60~Z180Coil
ID:508/610mm
ISO9001:2008
Coil Wgt.: 2.5~8Mt


STANDARD:

GB/T-12754: 2006, JIS3302, EN 10142, ASTM A653, JIS G3302, SGCC/SGCH, GB/T2518,

European Standard, ASTM A792, JIS G3321, JIS G3317

BASE PLATE:Cold rolled steel sheet, hot dipped zinc coated steel sheet, hot dipped A-Z coated

EQUIPMENT:;Double coating double baking; three coating three painting

CAPACITY:500,000Mt/year

SIZE: Thickness 0.16mm-1.2mm, width 700mm-1250mm

ZINC COATING: 60g-180g

PAINT THICKNESS:Top:20+-5um, back:5-7um

COIL WEIGHT:2.5Mt-8Mt

COIL ID:φ508mm-φ610mm

BASE SHEET:Cold rolled steel sheet, hot dipped zinc coated steel sheet (small, regular or zero spangle),hot dipped A-Z coated steel sheet

SURFACE PAINT:EP, PE, HDP, SMP, PVDF

COLOR SERIES: RAL color number series

SURFACE TYPE:Printed, embossed, corrugated

Packaging & Delivery:


Packaging Details:Standard seaworthy export packing: 3 layers of packing, inside is kraft paper, water plastic film is in the middle and outside GI steel sheet tp be covered by steel strips with lock, with inner coil sleeve. Other types of packing can be customized as per client's requirements.

Delivery Detail:15 days after received the deposit
