Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 m.t.
Supply Capability:30000 m.t./month
The main specifications as below:
1.Standards: GB/T 12754, JIS3312, EN10169, ASTM A755
2.Thickness: 0.17~0.7mm
3.Width: 914/1000/1200/1219/1220/1250mm etc.
4.Tolerance: +2/0mm
5.Thickness tolerance: +0.02/-0.02mm (or according to customers' request).
6.Coating mass: Top 13~15µ; Back 5~10µ
7.Coil weight: 5~8 Mteric tons
8.Coil DM.: I.D. φ508mm/610mm O.D.: Max φ1500mm
9.Coating type: PE. SMP. HDP. PVDF
Commom performance of front coating:
1). Thickness: ≥20µm
2). Pencil Hardness: 2H
3). 60° specular glossiness of coating: >60
4). 180° bend: ≤ 3T
5). Impact: ≥9J
6). Salt fog resistant: ≥500h
7). Color difference: <3∧E
| NAME | PPGL | GALVNIED | GLAVALUME/ALUZINC |
| CERTIFICATION | ISO9001/ISO14001 | ||
| STANDARD | GB/T-12754 JIS G 3312 EN 10169 ASTM A755 | GB/T-2518 JIS G 3302 EN 10142/10427 ASTM A653 | GB/T-14798 JIS G 3321 EN 10215 ASTM A792 |
| GRADE | SGCC DX51D SGCH CGCD1-CGCD3 CGC340-CGC570 | SS GRADE33-80 SGCC SGCH SGCD1-SGCD3 CGC340-CGC570 DX51D | SS GRADE33-80 SGLCC SGLCD SGCDD SGLC400-SGLC570 SZACC SZACH SZAC340R |
| MODEL NO. | 0.17~0.7MM | 0.14~0.8MM | 0.17~0.7MM |
| TYPE | Steel coil Stell plate/sheet Corrugated steel sheets/plates | Steel coil Steel sheets/plates Corrugated steel sheets/plates | Steel coil Steel sheets/plates Corrugated steel sheets/plates |
| TECHNIQUE | Hot rolled-cold rolled -galvalume/galvanized -PPGI/PPGL | Hot rolled-cold rolled -galvanized | Hot rolled-cold rolled -galvalume |
| SURFACE TREATMENT | Mini/regular/big/zero spangle, Chromate treatment /chromate-free treatment /untreated unoile/oiled, TENSION LEVELLERT SKIN PASS anti-fingerprint/un-anti-fingerprint, Coating,color | Mini/regular/big/zero spangle, Chromate treatment /chromate-free treatment /untreated unoile/oiled, TENSION LEVELLERT SKIN PASS anti-fingerprint/un-anti-fingerprint, Coating | |
| APPLICATION | Structural use ,roofing, corrugated roofing, commercial use, household appliance, industry, family | ||
| SPECIAL APPLICATION | Wear resistant steel, high-strength steel plate | ||
