Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
Galvanized steel coils base metal as ASTM 653A, G 30, Commercial quality, color normal white (9016 / 9003). (Refer to the sample provided for 0.30 and 0.32).
Top coat: 5mic primer + 12-15mic top coat (RMP)
Back coat: grey - 5-7MIC service coating
Dimensions & qty:
0.30*1219mm
0.32*1219mm
Packing & Shipping terms:
Container shipment. Eye to wall on wooden pallets with cardboard sleeves inside the coils. Sleeve thickness: 13—20mm. Straight winding (zero stagger).
Inner & outer bore protection to protect the coil edges
Maximum container load: around 21 MT,
Coil weight RANGE :5-7MT, COIL ID: 508MM
Guarantee for no scratches /and peeling off during roll forming process
No surface defects like paint starvation, paint cratering, paint skipping / non coated spots, burnt portions, no cross / surface dents.
Guarantee for no white rust, no edge damage, no edge waviness, no strip holes, no pitting /pin holes, no edge buildup due to zinc edge overacting, no drossing & cross dents.
PPGI coils must confirm the below mentioned mechanical properties like:
T Bend: 0T—3T
Reverse impact: 16J
Pencil hardness: H—2H
MEK double rub: >50
